Connector Coupling Housing Harting 19370031750 IP65 19-pin

Harting 19370031750 coupling housing is a 19-pin connector enclosure with IP65 protection level designed for demanding industrial and automation environments. The housing provides a sealed mechanical shell that accommodates 19-pin inserts and secures the connection against dust and water jets. Built to match standard Harting coupling systems, it supports reliable panel or cable connections where environmental protection and mechanical robustness are required.

Advantages

The coupling housing delivers rated IP65 protection to guard contacts and inserts from dust ingress and low-pressure water jets. Its durable construction ensures mechanical stability and repeated mating cycles without compromising seal integrity. The design allows straightforward assembly with compatible 19-pin inserts and provides secure locking for stable electrical connections in industrial installations.

Suitable for

• Industrial machine tool connections requiring dust and splash protection
• Automation panels and junction boxes where a 19-pin interface is needed
• Cable-to-panel feedthroughs in workshops and production lines
• Enclosures where a robust, lockable connector housing is required

Key specifications

• Number of contacts: 19 positions for corresponding inserts
• Protection rating: IP65 against dust and water jets when mated and sealed
• Mounting style: coupling housing for panel or cable use with locking mechanism
• Material: rugged thermoplastic or metal composite designed for industrial use
• Compatibility: fits standard 19-pin rectangular inserts and mating halves in the same series
• Environmental resistance: designed for industrial temperature ranges and mechanical stress (repeated mating)

How to use

Select a compatible 19-pin insert and ensure contact terminations are completed according to the insert manufacturer's instructions. Mount the coupling housing to the panel cutout or assemble it onto the cable assembly following the housing alignment features. Insert the wired insert into the housing until it engages securely and close the housing latch to achieve the IP65 seal. Verify the mechanical lock and perform a continuity or insulation check before energizing the circuit.

Usage recommendations

Use the housing with mating components from the same connector series to preserve IP65 performance. Inspect sealing surfaces and the latch before installation, avoid exposing the sealed connector to high-pressure washings beyond IP65 rating, and follow regular maintenance checks in dusty or wet environments to ensure long-term reliability.
