Type:
-
IP security camera
-
Weight:
-
0.485 kg
-
Certification:
-
FCC (47 CFR 15, B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015);KC (KN 32: 2015, KN 35: 2015)
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014 ); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014 ); BIS (IS 13252(1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1)
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach ( (EC) No 1907/2006)
-
Supported network protocols:
-
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP
-
Operating relative humidity (H-H):
-
0 - 95
-
Compatible memory cards:
-
MicroSD (TransFlash), MicroSDHC, MicroSDXC
-
Storage temperature (T-T):
-
-30 - 60
-
Package weight:
-
724 g
-
Form factor:
-
Bullet
-
Built-in microphone:
-
Yes
-
Operating temperature (T-T):
-
-30 - 60
-
Camera shutter speed:
-
1/3 - 1/100000
-
Ethernet LAN:
-
Yes
-
Storage relative humidity (H-H):
-
0 - 95
-
Sensor type:
-
CMOS
-
Optical sensor size:
-
25.4 / 3
-
Connectivity technology:
-
Wired
-
Maximum resolution:
-
2688 x 1520
-
Product colour:
-
White
-
Number of users:
-
32 user(s)
-
Networking standards:
-
IEEE 802.1x, IEEE 802.3af
-
Voice codecs:
-
AAC, G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, PCM
-
LED type:
-
IR
-
Tilt angle range:
-
0 - 90
-
Bluetooth:
-
No
-
Audio formats supported:
-
MP3
-
Video compression formats:
-
H.264, H.264+, H.265, H.265+, M-JPEG
-
Bit rate:
-
32 Kbps - 8 Mbps
-
Ethernet LAN (RJ-45) ports:
-
1
-
Angle of rotation:
-
360 °
-
Noise reduction:
-
Yes
-
Length:
-
161.7 mm
-
Pan range:
-
0 - 360
-
Diameter:
-
70 mm
-
Languages support:
-
BUL, CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, JPN, KOR, LAT, LIT, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, THA, TUR, UKR, VIE
-
Progressive scan:
-
Yes
-
Wi-Fi:
-
No
-
Quality of Service (QoS) support:
-
Yes
-
Card reader integrated:
-
Yes
-
Placement supported:
-
Outdoor
-
Frame rate:
-
30 fps
-
Mirror:
-
Yes
-
Package depth:
-
121 mm
-
Package height:
-
118 mm
-
Package width:
-
216 mm
-
Supported graphics resolutions:
-
640 x 360, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2688 x 1520
-
Housing material:
-
Aluminium
-
Maximum aperture number:
-
1.4
-
Night vision:
-
Yes
-
Fixed focal length:
-
4 mm
-
Mounting type:
-
Ceiling/Wall
-
Video motion detection:
-
Yes
-
IP address filtering:
-
Yes
-
DC output voltage:
-
12
-
DC output current:
-
0.5 A
-
Maximum memory card size:
-
256 GB
-
Number of languages:
-
33
-
Ethernet interface type:
-
Fast Ethernet
-
International Protection (IP) code:
Device protection rating against dust and water according to the international IP standard.
-
IP67
-
Power source type:
-
DC, PoE
-
Total megapixels:
-
4 MP
-
Image quality adjustment:
-
Brightness, Contrast, Saturation, Sharpness
-
Back Light Compensation (BLC):
-
Yes
-
Built-in HDD:
-
No
-
Night vision distance:
-
40
-
HTTPS encryption:
-
Yes
-
Wide Dynamic Range (WDR):
-
Yes
-
Infra-red wavelength:
-
850 nm
-
Day/night mode:
-
Yes
-
Number of cameras:
-
1
-
Power consumption (max):
-
6 W
-
Sample rate:
-
48 kHz
-
Video streaming:
-
Yes
-
Password protection:
-
Yes
-
Number of lenses:
-
1
-
Privacy masking:
-
Yes
-
Power consumption (Power over Ethernet (PoE)):
-
7 W
-
Infrared (IR) cut-off filter:
-
Yes
-
Number of sensors:
-
1
-
Detect distance (wide):
-
80 m
-
Observe distance (wide):
-
31.7 m
-
Recognize distance (wide):
-
16 m
-
Identify distance (wide):
-
8 m
-
Intelligent Video Surveillance (IVS) system features:
-
Scene change
-
Highlight Compensation (HLC):
-
Yes
-
Bit rate control:
-
Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
-
Region of Interest (ROI) encoding:
-
Yes
-
Noise reduction technology:
-
3D noise reduction
-
Anti-flicker:
-
Yes
-
Heartbeat:
-
Yes
-
Behavior analysis:
-
Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection
-
Camera pan control:
-
Yes
-
Camera tilt control:
-
Yes
-
Sustainability certificates:
-
CE, REACH
-
Lens viewing angle, horizontal:
-
83
-
Lens viewing angle, vertical:
-
45
-
Lens viewing angle, diagonal:
-
98
