Type:
-
IP security camera
-
Digital zoom:
-
16 x
-
Optical zoom:
-
21 x
-
Weight:
-
10 kg
-
Certification:
-
EMC
FCC (47 CFR Part 15, Subpart B),CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013 + A1: 2019, EN 50130-4: 2011 + A1: 2014),RCM (AS/NZS CISPR 32: 2015),IC (ICES-003: Issue 7),KC (KN 32: 2015, KN 35: 2015)
Safety
CE-LVD (EN 62368-1: 2014/A11: 2017),CB (IEC 62368-1: 2014 + A11),UL (UL 62368-1),BIS (IS 13252 (Part 1): 2010/IEC 60950-1: 2005),LOA (IEC/EN 60950-1)
Environment
CE-RoHS (2011/65/EU),WEEE (2012/19/EU),Reach (Regulation (EC) No 1907/2006)
-
Security algorithms:
-
EAP-LEAP, EAP-MD5, EAP-TLS
-
Zoom capability:
-
Yes
-
Supported network protocols:
-
IPv4/IPv6,HTTP,HTTPS,802.1X,QoS,FTP,TCP/IP,ICMP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,PPPoE,UPnP,SMTP,SNMP,IGMP,UDP,Bonjour,NTP
-
Operating relative humidity (H-H):
-
0 - 95
-
Compatible memory cards:
-
MicroSD (TransFlash), MicroSDHC, MicroSDXC
-
Form factor:
-
Bulb
-
Operating temperature (T-T):
-
-40 - 70
-
Camera shutter speed:
-
1/1 - 1/30000
-
Ethernet LAN:
-
Yes
-
Height:
-
430 mm
-
Focal length range:
-
5.9 - 147.5
-
Sensor type:
-
CMOS
-
Image stabilizer:
-
Yes
-
Auto focus:
-
Yes
-
Optical sensor size:
-
25.4 / 1.8
-
Connectivity technology:
-
Wired
-
Maximum resolution:
-
2560 x 1440
-
Product colour:
-
Black, Silver
-
Number of users:
-
32 user(s)
-
Networking standards:
-
IEEE 802.1x
-
LED type:
-
IR
-
Tilt angle range:
-
-20 - 90
-
Bluetooth:
-
No
-
Audio formats supported:
-
G.711 A-law, G.711 μ-law, G.722.1, G.726, MP2L2, PCM
-
Video compression formats:
-
H.264, H.264+, H.265, H.265+, M-JPEG
-
Bit rate:
-
32 Kbps - 16 Mbps
-
Ethernet LAN (RJ-45) ports:
-
1
-
Headphone outputs:
-
1
-
Microphone in:
-
Yes
-
Noise reduction:
-
Yes
-
Pan range:
-
0 - 360
-
Pan speed:
-
210 °/sec
-
Tilt speed:
-
150 °/sec
-
Diameter:
-
267 mm
-
Dynamic range:
-
140 dB
-
Languages support:
-
ENG, NOR, ESP, SWE, BUL, EST, ITA, POL, THA, FIN, JPN, POR, TUR, FRE, RUM, UKR, CHI (TR), GRE, KOR, RUS, VIE, CZE, LAT, DAN, LAV, SER, DEU, HRV, SLK, DUT, HUN, SLV
-
Progressive scan:
-
Yes
-
Wi-Fi:
-
No
-
Quality of Service (QoS) support:
-
Yes
-
Card reader integrated:
-
Yes
-
Placement supported:
-
Indoor & outdoor
-
Frame rate:
-
25 fps
-
Supported graphics resolutions:
-
352 x 240, 352 x 288, 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080), 2560 x 1440
-
Maximum aperture number:
-
1.6
-
Night vision:
-
Yes
-
Mounting type:
-
Ceiling
-
Video motion detection:
-
Yes
-
Active tampering alarm:
-
Yes
-
IP address filtering:
-
Yes
-
DC output voltage:
-
36
-
Maximum memory card size:
-
256 GB
-
Number of languages:
-
33
-
BNC output ports:
-
1
-
Ethernet interface type:
-
Fast Ethernet
-
PTZ control:
-
Yes
-
RS-485 ports:
-
1
-
International Protection (IP) code:
Device protection rating against dust and water according to the international IP standard.
-
IP67
-
Power source type:
-
DC, PoE
-
Total megapixels:
-
4 MP
-
Image quality adjustment:
-
Brightness, Contrast, Saturation, Sharpness
-
Back Light Compensation (BLC):
-
Yes
-
Built-in HDD:
-
No
-
Night vision distance:
-
300
-
Built-in light:
-
Yes
-
Auto-tracking:
-
Yes
-
HTTPS encryption:
-
Yes
-
Wide Dynamic Range (WDR):
-
Yes
-
Day/night mode:
-
Yes
-
Number of cameras:
-
1
-
Power consumption (max):
-
62 W
-
IK code:
-
IK10
-
Password protection:
-
Yes
-
Alarm input channels:
-
7
-
Alarm output channels:
-
2
-
Number of lenses:
-
1
-
Preset points:
-
Yes
-
Privacy masking:
-
Yes
-
Infrared (IR) cut-off filter:
-
Yes
-
Digital watermark:
-
Yes
-
PTZ modes:
-
4 Pattern, Auto Scan, Preset point
-
Web browser:
-
Yes
-
Intelligent Video Surveillance (IVS) system features:
-
Crossing line, Face detection, Human detection, Intrusion, Region entrance detection, Region exiting detection, Vehicle detection
-
Highlight Compensation (HLC):
-
Yes
-
Region of Interest (ROI) encoding:
-
Yes
-
Pan preset speed:
-
280 °/sec
-
Tilt preset speed:
-
250 °/sec
-
PTZ protocols:
-
PELCO-P/D
-
Auto flip:
-
Yes
-
Noise reduction technology:
-
3D noise reduction
-
Behavior analysis:
-
Intrusion detection, Line crossing detection, Object removal detection, Region entrance detection, Region exiting detection, Unattended baggage detection
-
Camera pan control:
-
Yes
-
Camera tilt control:
-
Yes
-
Bit rate range:
-
16 - 192
-
Number of simultaneous live view channels:
-
20 channels
-
User access level:
-
Administrator, Operator, User
-
Human and vehicle targets classification:
-
Yes
-
Lens viewing angle, horizontal:
-
59 - 3.05
-
Lens viewing angle, vertical:
-
34.28 - 1.73
-
Lens viewing angle, diagonal:
-
66.92 - 3.49
-
Basic event:
-
Motion detection, video tampering alarm, alarm input, alarm output, exception
