Type:
-
IP security camera
-
Weight:
-
0.53 kg
-
Certification:
-
CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,
RCM: AS/NZS CISPR 32: 2015,
IC: ICES-003: Issue 7,
KC: KN32: 2015, KN35: 2015
UL: UL 62368-1,
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017
CE-RoHS: 2011/65/EU
IP67: IEC 60529-2013
NEMA 4X (NEMA 250-2018)
-
Audio system:
-
2-way
-
Security algorithms:
-
EAP-LEAP, EAP-MD5, EAP-TLS, TLS
-
Supported network protocols:
-
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP
-
Operating relative humidity (H-H):
-
0 - 95
-
Compatible memory cards:
-
MicroSD (TransFlash), MicroSDHC, MicroSDXC
-
Storage temperature (T-T):
-
-30 - 60
-
Package weight:
-
810 g
-
Form factor:
-
Bullet
-
Built-in microphone:
-
Yes
-
Operating temperature (T-T):
-
-30 - 60
-
Camera shutter speed:
-
1 - 1/100000
-
Ethernet LAN:
-
Yes
-
Storage relative humidity (H-H):
-
0 - 95
-
Signal-to-Noise Ratio (SNR):
-
52 dB
-
Sensor type:
-
CMOS
-
Minimum illumination:
-
0 lx
-
Optical sensor size:
-
25.4 / 1.8
-
Connectivity technology:
-
Wired
-
Maximum resolution:
-
2688 x 1520
-
Product colour:
-
White
-
Number of users:
-
32 user(s)
-
Networking standards:
-
IEEE 802.1x, IEEE 802.3af
-
LED type:
-
IR/White
-
Tilt angle range:
-
0 - 90
-
Bluetooth:
-
No
-
Video compression formats:
-
H.264, H.264+, H.265, H.265+, M-JPEG
-
Bit rate:
-
32 Kbps - 8 Mbps
-
Ethernet LAN (RJ-45) ports:
-
1
-
Angle of rotation:
-
360 °
-
Noise reduction:
-
Yes
-
Length:
-
176.3 mm
-
Pan range:
-
0 - 360
-
Diameter:
-
74.4 mm
-
Dynamic range:
-
130 dB
-
Languages support:
-
Multi
-
Progressive scan:
-
Yes
-
Wi-Fi:
-
No
-
Card reader integrated:
-
Yes
-
Placement supported:
-
Indoor & outdoor
-
Frame rate:
-
30 fps
-
Mirror:
-
Yes
-
Reset button:
-
Yes
-
Package depth:
-
120 mm
-
Package height:
-
117 mm
-
Package width:
-
234 mm
-
Supported graphics resolutions:
-
640 x 360, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2688 x 1520
-
Audio codecs:
-
G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
-
Housing material:
-
Metal
-
Maximum aperture number:
-
1
-
Night vision:
-
Yes
-
Live view:
-
Yes
-
Audit log:
-
Yes
-
Fixed focal length:
-
2.8 mm
-
Mounting type:
-
Ceiling/Wall
-
Video motion detection:
-
Yes
-
Active tampering alarm:
-
Yes
-
IP address filtering:
-
Yes
-
Video formats supported:
-
H.264, H.264+, H.265, H.265+, M-JPEG
-
DC output voltage:
-
12
-
DC output current:
-
0.4 A
-
Maximum memory card size:
-
512 GB
-
Number of languages:
-
33
-
Number of microphones:
-
2
-
Ethernet interface type:
-
Fast Ethernet
-
International Protection (IP) code:
Device protection rating against dust and water according to the international IP standard.
-
IP67
-
Power source type:
-
DC, PoE
-
Total megapixels:
-
4 MP
-
Image quality adjustment:
-
Brightness, Contrast, Sharpness
-
Back Light Compensation (BLC):
-
Yes
-
Protection features:
-
Dust resistant, Water resistant
-
Night vision distance:
-
40
-
HTTPS encryption:
-
Yes
-
Wide Dynamic Range (WDR):
-
Yes
-
Infra-red wavelength:
-
850 nm
-
Day/night mode:
-
Yes
-
Number of cameras:
-
1
-
Power consumption (max):
-
4.8 W
-
Video streaming:
-
Yes
-
Sample rates:
-
8 - 48
-
Password protection:
-
Yes
-
Number of lenses:
-
1
-
Power consumption (Power over Ethernet (PoE)):
-
6.5 W
-
Alert notification type:
-
E-mail
-
Infrared (IR) cut-off filter:
-
Yes
-
Digital watermark:
-
Yes
-
Number of sensors:
-
1
-
Web browser:
-
Yes
-
Gain control type:
-
Auto
-
Intelligent Video Surveillance (IVS) system features:
-
Face detection, Scene change
-
Highlight Compensation (HLC):
-
Yes
-
Bit rate control:
-
Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
-
Region of Interest (ROI) encoding:
-
Yes
-
Observe distance:
-
24 m
-
Detect distance:
-
61 m
-
Recognize distance:
-
12 m
-
Identify distance:
-
6 m
-
Noise reduction technology:
-
3D noise reduction
-
Heartbeat:
-
Yes
-
Behavior analysis:
-
Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection
-
Bit rate range:
-
8 - 320
-
Number of simultaneous live view channels:
-
6 channels
-
User access level:
-
Administrator, Operator, User
-
Password reset via email:
-
Yes
-
Pixel counter:
-
Yes
-
Flash log:
-
Yes
-
Automatic Network Replenishment (ANR):
-
Yes
-
Digest authentication:
-
Yes
-
Lens viewing angle, horizontal:
-
111.1
-
Lens viewing angle, vertical:
-
57.6
-
Lens viewing angle, diagonal:
-
138.5
-
Number of Privacy masking areas:
-
4
-
Network access storage (NAS):
-
Yes
