Type:
-
IP security camera
-
Weight:
-
0.38 kg
-
Certification:
-
FCC: 47 CFR Part 15, Subpart B,
CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN
50130-4: 2011 +A1: 2014,
IC: ICES-003: Issue 7,
KC: KN32: 2015, KN35: 2015
UL: UL 62368-1,
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006
-
Security algorithms:
-
EAP-LEAP, EAP-MD5, EAP-TLS
-
I/O ports:
-
1x line in, 1x line out
-
Supported network protocols:
-
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE
-
Operating relative humidity (H-H):
-
0 - 95
-
Compatible memory cards:
-
MicroSD (TransFlash)
-
Storage temperature (T-T):
-
-30 - 60
-
Package weight:
-
620 g
-
Form factor:
-
Dome
-
Built-in microphone:
-
Yes
-
Operating temperature (T-T):
-
-30 - 60
-
Camera shutter speed:
-
1/3 - 1/100000
-
Ethernet LAN:
-
Yes
-
Storage relative humidity (H-H):
-
0 - 95
-
Height:
-
57.4 mm
-
Signal-to-Noise Ratio (SNR):
-
52 dB
-
Sensor type:
-
CMOS
-
Optical sensor size:
-
25.4 / 2.8
-
Connectivity technology:
-
Wired
-
Maximum resolution:
-
1920 x 1080
-
Product colour:
-
White
-
Number of users:
-
32 user(s)
-
Networking standards:
-
IEEE 802.1x, IEEE 802.3af
-
LED type:
-
IR
-
Tilt angle range:
-
0 - 75
-
Bluetooth:
-
No
-
Audio output channels:
-
1
-
Audio formats supported:
-
G.711, G.722.1, MP2L2, G.726, MP3, AAC-LC, PCM
-
Video compression formats:
-
H.264, H.264+, H.265, H.265+, M-JPEG
-
Bit rate:
-
32 Kbps - 8 Mbps
-
Ethernet LAN (RJ-45) ports:
-
1
-
Angle of rotation:
-
360 °
-
Noise reduction:
-
Yes
-
Pan range:
-
-30 - 30
-
Diameter:
-
110 mm
-
Dynamic range:
-
120 dB
-
Languages support:
-
Multi
-
Progressive scan:
-
Yes
-
Wi-Fi:
-
No
-
Quality of Service (QoS) support:
-
Yes
-
Card reader integrated:
-
Yes
-
Placement supported:
-
Outdoor
-
Frame rate:
-
30 fps
-
Web-based management:
-
Yes
-
Mirror:
-
Yes
-
Reset button:
-
Yes
-
Package depth:
-
134 mm
-
Package height:
-
108 mm
-
Package width:
-
134 mm
-
Supported graphics resolutions:
-
1280 x 720 (HD 720), 640 x 480 (VGA), 640 x 360, 1920 x 1080 (HD 1080)
-
Housing material:
-
Aluminium, Plastic
-
Maximum aperture number:
-
1.4
-
Night vision:
-
Yes
-
Live view:
-
Yes
-
Client interoperability:
-
iVMS-4200, Hik-Connect, Hik-Central
-
Fixed focal length:
-
2.8 mm
-
Mounting type:
-
Ceiling/Wall
-
Video motion detection:
-
Yes
-
Active tampering alarm:
-
Yes
-
IP address filtering:
-
Yes
-
DC output voltage:
-
12
-
DC output current:
-
0.45 A
-
Maximum memory card size:
-
256 GB
-
Number of languages:
-
33
-
Ethernet interface type:
-
Fast Ethernet
-
International Protection (IP) code:
Device protection rating against dust and water according to the international IP standard.
-
IP67
-
Power source type:
-
DC, PoE
-
Total megapixels:
-
2 MP
-
Image quality adjustment:
-
Brightness, Contrast, Sharpness, Saturation
-
Back Light Compensation (BLC):
-
Yes
-
Built-in HDD:
-
No
-
Night vision distance:
-
30
-
Audio input channels:
-
1
-
HTTPS encryption:
-
Yes
-
Wide Dynamic Range (WDR):
-
Yes
-
Infra-red wavelength:
-
850 nm
-
Day/night mode:
-
Yes
-
Alarm input/output:
-
Yes
-
Number of cameras:
-
1
-
Power consumption (max):
-
5.5 W
-
Lens mount interface:
-
M12
-
IK code:
-
IK08
-
Video streaming:
-
Yes
-
Sample rates:
-
8 - 48
-
Password protection:
-
Yes
-
Alarm input channels:
-
1
-
Alarm output channels:
-
1
-
Number of lenses:
-
1
-
Privacy masking:
-
Yes
-
Power consumption (Power over Ethernet (PoE)):
-
6.5 W
-
Privacy protection:
-
Yes
-
Infrared (IR) cut-off filter:
-
Yes
-
Digital watermark:
-
Yes
-
Number of sensors:
-
1
-
Intelligent Video Surveillance (IVS) system features:
-
Intrusion, Region entrance detection, Face detection, Region exiting detection, Crossing line
-
Highlight Compensation (HLC):
-
Yes
-
Bit rate control:
-
Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
-
Region of Interest (ROI) encoding:
-
Yes
-
Observe distance:
-
17 m
-
Detect distance:
-
44 m
-
Recognize distance:
-
9 m
-
Identify distance:
-
4 m
-
Noise reduction technology:
-
3D noise reduction
-
Anti-flicker:
-
Yes
-
Heartbeat:
-
Yes
-
Behavior analysis:
-
Intrusion detection, Region exiting detection, Line crossing detection, Region entrance detection
-
Camera pan control:
-
Yes
-
Camera tilt control:
-
Yes
-
Bit rate range:
-
8 - 320
-
Number of simultaneous live view channels:
-
6 channels
-
User access level:
-
Administrator, Operator, User
-
Password reset via email:
-
Yes
-
Pixel counter:
-
Yes
-
Automatic Network Replenishment (ANR):
-
Yes
-
Lens viewing angle, horizontal:
-
107
-
Lens viewing angle, vertical:
-
57
-
Lens viewing angle, diagonal:
-
129
