Type:
Characteristics of the device.
-
IP security camera
-
Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
1.075 kg
-
Certification:
-
FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); KC (KN 32: 2015, KN 35: 2015)
UL (UL 60950-1);
CB (IEC 60950-1: 2005 + Am 1: 2009 + Am 2: 2013);
CE-LVD (EN 60950-1: 2005 + Am 1: 2009 + Am 2: 2013);
LOA (IEC/EN 60950-1)
CE-ROHS (2011/65/EU); WEEE (2012/19/EU); REACH (Regulation (EC) No 1907/2006)
-
Security algorithms:
Security algorithms are used to provide authentication, cipher key generation, integrity and radio link privacy to users on mobile networks. The security algorithms supported are the ones that can be used with this product.
-
TLS
-
Supported network protocols:
Network protocols tested as compatible with this product e.g. FTP,HTML, POP.
-
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP
-
Operating relative humidity (H-H):
-
0 - 95
-
Compatible memory cards:
Types of memory cards which can be used with this product.
-
MicroSD (TransFlash), MicroSDHC, MicroSDXC
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-30 - 60
-
Package weight:
Weight of the packaged product.
-
1525 g
-
Form factor:
The shape or design of the product.
-
Dome
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
-30 - 60
-
Camera shutter speed:
Determines the length of time the shutter lets light pass through the lens to the CCD. Shutter speed and aperture together determine exposure.
-
1/3 - 1/100000
-
Ethernet LAN:
An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
-
Yes
-
Storage relative humidity (H-H):
-
0 - 95
-
Focal length range:
Measure of how strongly the system converges or diverges light. For an optical system in air, it is the distance over which initially collimated rays are brought to a focus. A system with a shorter focal length has greater optical power than one with a long focal length; that is, it bends the rays more strongly, bringing them to a focus in a shorter distance.For an optical system in air, the effective focal length (f and f′) gives the distance from the front and rear principal planes (H and H′) to the corresponding focal points (F and F′).
-
2.8 - 12
-
Signal-to-Noise Ratio (SNR):
This is the ratio of signal intensity to noise intensity.
-
52 dB
-
Sensor type:
A sensor is a convertor than measures a physical quality (light, temperature etc.) and displays this electronically on a device.
-
CMOS
-
Optical sensor size:
Optical sensors are electronic detectors that convert light, or a change in light, into an electronic signal. They are used in many industrial and consumer applications e.g. lamps that turn on automatically in response to darkness. Optical sensors come in many sizes.
-
25.4 / 3
-
Connectivity technology:
The technology that enables connectivity of the device, e.g. wired or wireless.
-
Wired
-
Maximum resolution:
The maximum number of pixels that can be displayed in the image. It is usually quoted as width × height,: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels.
-
2688 x 1520
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Black
-
Number of users:
The number of people that use or can use this product.
-
32 user(s)
-
Networking standards:
The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
-
IEEE 802.3af
-
Voice codecs:
-
AAC, G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, PCM
-
LED type:
-
IR
-
Tilt angle range:
-
0 - 75
-
Bluetooth:
Bluetooth is a low-power radio technology developed to replace the cables and wires currently used to link or connect electronic devices such as personal computers, printers, and a wide variety of handheld devices including mobile phones. Because it uses radio-wave connectivity, a Bluetooth-enabled device has a constant, established connection to whatever browser it uses. This saves the user the trouble of logging on to check for emails or news updates, for example.
-
No
-
Audio output channels:
An audio output channel is an electric circuit which acts as a path for a signal produced by a device. A device may have several audio output channels.
-
1
-
Video compression formats:
-
H.264, H.264+, H.265, H.265+, M-JPEG
-
Bit rate:
-
32 Kbps - 8 Mbps
-
Ethernet LAN (RJ-45) ports:
Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.
-
1
-
Angle of rotation:
-
360 °
-
Noise reduction:
-
Yes
-
Length:
The measurement or extent of something from end to end.
-
145.5 mm
-
Pan range:
-
0 - 355
-
Diameter:
Distance from one side of a body (circle or sphere) to the other side, measured by a straight line passing through the centre of the body.
-
135.8 mm
-
Languages support:
The product has support (help) for languages.
-
Multi
-
Progressive scan:
Also referred to as noninterlaced scanning, this is a way of displaying, storing, or transmitting moving images in which all the lines of each frame are drawn in sequence. This is in contrast to interlaced video used in traditional analog television systems where only the odd lines, then the even lines of each frame (each image called a video field) are drawn alternately.Progressive scan is used for DVDs and HDTV (high defintion television).
-
Yes
-
Wi-Fi:
Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.
-
No
-
Quality of Service (QoS) support:
-
Yes
-
Card reader integrated:
A card reader is a device that enables reading and, in some cases, writing data to and from a memory card.
-
Yes
-
Placement supported:
Where the product can be placed e.g. indoor/outdoor, horizontal/vertical.
-
Indoor & outdoor
-
Frame rate:
-
30 fps
-
Mirror:
-
Yes
-
Reset button:
-
Yes
-
Package depth:
The distance from the front to the back of the packaging.
-
170 mm
-
Package height:
The distance from the top to the bottom of the packaging.
-
205 mm
-
Package width:
The distance from one side of the packaging to the other.
-
170 mm
-
Supported graphics resolutions:
The graphic resolutions that can be displayed by the device. The graphic resolution describes the width and height dimensions of a display, such as a computer monitor, measured in pixels.
-
640 x 360, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2688 x 1520
-
Maximum aperture number:
-
1.4
-
Night vision:
Night vision is technology which allows you to see in low light conditions.
-
Yes
-
Audit log:
-
Yes
-
Mounting type:
Type of mounting e.g. wall mounting.
-
Ceiling/Wall
-
Video motion detection:
-
Yes
-
Active tampering alarm:
-
Yes
-
IP address filtering:
-
Yes
-
DC output voltage:
-
12
-
DC output current:
-
0.92 A
-
Maximum memory card size:
The maximum size of memory card that can be used with this device.
-
256 GB
-
Number of languages:
-
33
-
Ethernet interface type:
-
Fast Ethernet
-
International Protection (IP) code:
The IP code classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. It is published by the International Electrotechnical Commission (IEC). The digits (characteristic numerals) indicate conformity with the conditions summarized in the tables below. Where there is no protection rating with regard to one of the criteria, the digit is replaced with the letter X. an electrical socket rated IP22 is protected against insertion of fingers and will not be damaged or become unsafe during a specified test in which it is exposed to vertically or nearly vertically dripping water. Another example is the Sony Xperia Z Ultra, one of the first cellular phones to be IP-rated; it is rated at IP58 and marketed as "dust resistant" and can be "immersed in 1.5 meter of freshwater for up to 30 minutes".
-
IP66
-
Power source type:
What the power source is.
-
DC, PoE
-
Total megapixels:
A megapixel (MP or Mpx) is one million pixels, and is a term used not only for the number of pixels in an image, but also to express the number of image sensor elements of digital cameras or the number of display elements of digital displays. For example, a camera that makes a 2048 × 1536 pixel image typically uses a few extra rows and columns of sensor elements and is commonly said to have "3.2 megapixels" or "3.4 megapixels", depending on whether the number reported is the "effective" or the "total" pixel count (as opposed to the 2048 × 1536 = 3,145,728 finished image pixels).
-
4 MP
-
Image quality adjustment:
-
Brightness, Contrast, Saturation, Sharpness
-
Back Light Compensation (BLC):
-
Yes
-
Protection features:
Physical effects from which the product is protected e.g. water resistant, crash proof.
-
Dust resistant, Vandal proof, Water resistant
-
Built-in HDD:
The product has a hard drive built into it.
-
No
-
Night vision distance:
-
40
-
Audio input channels:
A channel is an electric circuit which acts as a path for a signal. Audio input channels allow audio signals to be communicated to the device.
-
1
-
HTTPS encryption:
-
Yes
-
Wide Dynamic Range (WDR):
-
Yes
-
Infra-red wavelength:
-
850 nm
-
Day/night mode:
-
Yes
-
Alarm input/output:
-
Yes
-
Number of cameras:
The quantity of cameras that product can support.
-
1
-
Power consumption (max):
The maximum amount of power used by the device.
-
11 W
-
IK code:
-
IK10
-
Video streaming:
-
Yes
-
Sample rates:
-
8 - 48
-
Password protection:
The computer, smartphone etc. can only be used when the correct password is entered, therefore making it more secure.
-
Yes
-
Number of lenses:
The number of lenses installed in the device.
-
1
-
Privacy masking:
-
Yes
-
Power consumption (Power over Ethernet (PoE)):
-
12.5 W
-
Alert notification type:
-
E-mail
-
Infrared (IR) cut-off filter:
-
Yes
-
Number of sensors:
-
1
-
Web browser:
-
Yes
-
Gain control type:
-
Auto
-
Detect distance (wide):
-
64 m
-
Detect distance (tele):
-
190 m
-
Observe distance (wide):
-
25.4 m
-
Observe distance (tele):
-
75.4 m
-
Recognize distance (wide):
-
12.8 m
-
Recognize distance (tele):
-
38 m
-
Identify distance (wide):
-
6.4 m
-
Identify distance (tele):
-
19 m
-
Intelligent Video Surveillance (IVS) system features:
-
Face detection, Scene change
-
Highlight Compensation (HLC):
-
Yes
-
Bit rate control:
-
Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
-
Region of Interest (ROI) encoding:
-
Yes
-
Noise reduction technology:
-
3D noise reduction
-
Anti-flicker:
-
Yes
-
Heartbeat:
-
Yes
-
Behavior analysis:
-
Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection
-
Camera pan control:
-
Yes
-
Camera tilt control:
-
Yes
-
Password reset via email:
-
Yes
-
Pixel counter:
-
Yes
-
Lens viewing angle, horizontal:
-
108
-
Lens viewing angle, vertical:
-
56
-
Lens viewing angle, diagonal:
-
131
