Type:
-
IP security camera
-
Weight:
-
1.42 kg
-
Certification:
-
FCC: 47 CFR Part 15, Subpart B,
CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,
RCM: AS/NZS CISPR 32: 2015,
IC: ICES-003: Issue 7
UL: UL 62368-1,
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006
-
Security algorithms:
-
HTTPS
-
Supported network protocols:
-
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP
-
Operating relative humidity (H-H):
-
0 - 95
-
Compatible memory cards:
-
MicroSD (TransFlash), MicroSDHC, MicroSDXC
-
Storage temperature (T-T):
-
-30 - 60
-
Package weight:
-
2228 g
-
Form factor:
-
Bullet
-
Operating temperature (T-T):
-
-30 - 60
-
Camera shutter speed:
-
1/3 - 1/100000
-
Ethernet LAN:
-
Yes
-
Storage relative humidity (H-H):
-
0 - 95
-
Height:
-
78 mm
-
Signal-to-Noise Ratio (SNR):
-
52 dB
-
Sensor type:
-
CMOS
-
Minimum illumination:
-
0.0005 lx
-
Optical sensor size:
-
25.4 / 1.8
-
Width:
-
118.6 mm
-
Depth:
-
341.4 mm
-
Connectivity technology:
-
Wired
-
Maximum resolution:
-
5120 x 1440
-
Product colour:
-
Black, White
-
Number of users:
-
32 user(s)
-
Tilt angle range:
-
0 - 90
-
Bluetooth:
-
No
-
Audio output channels:
-
1
-
Audio formats supported:
-
AAC-LC, G.711, G.722.1, G.726, MP2L2, MP3, PCM
-
Video compression formats:
-
H.264, H.264+, H.265, H.265+, M-JPEG
-
Bit rate:
-
32 Kbps to 16 Mbps
-
Ethernet LAN (RJ-45) ports:
-
1
-
Microphone in:
-
Yes
-
Angle of rotation:
-
360 °
-
Built-in speaker(s):
-
Yes
-
Noise reduction:
-
Yes
-
Pan range:
-
0 - 355
-
Diameter:
-
105.1 mm
-
Dynamic range:
-
130 dB
-
Languages support:
-
CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, JPN, KOR, LAT, LIT, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, THA, TUR, UKR, VIE
-
Wi-Fi:
-
No
-
Card reader integrated:
-
Yes
-
Placement supported:
-
Indoor & outdoor
-
Frame rate:
-
20 fps
-
Reset button:
-
Yes
-
Package depth:
-
190 mm
-
Package height:
-
180 mm
-
Package width:
-
405 mm
-
Supported graphics resolutions:
-
960 x 272, 1920 x 536, 5120 x 1440
-
Housing material:
-
Metal
-
Maximum aperture number:
-
1
-
Fixed focal length:
-
4 mm
-
Mounting type:
-
Wall
-
Video motion detection:
-
Yes
-
IP address filtering:
-
Yes
-
DC output voltage:
-
12
-
DC output current:
-
0.79 A
-
Maximum memory card size:
-
256 GB
-
Number of languages:
-
33
-
International Protection (IP) code:
Device protection rating against dust and water according to the international IP standard.
-
IP67
-
Power source type:
-
DC, PoE
-
Total megapixels:
-
8 MP
-
Image quality adjustment:
-
Brightness, Saturation, Sharpness
-
Back Light Compensation (BLC):
-
Yes
-
Built-in HDD:
-
Yes
-
Audio input channels:
-
1
-
Built-in light:
-
Yes
-
Wide Dynamic Range (WDR):
-
Yes
-
Number of cameras:
-
1
-
Power consumption (max):
-
9.5 W
-
Password protection:
-
Yes
-
Power consumption (Power over Ethernet (PoE)):
-
10.5 W
-
Digital watermark:
-
Yes
-
Number of sensors:
-
2
-
Web browser:
-
Yes
-
Detect distance (wide):
-
77 m
-
Observe distance (wide):
-
30 m
-
Recognize distance (wide):
-
15 m
-
Identify distance (wide):
-
7 m
-
Highlight Compensation (HLC):
-
Yes
-
Bit rate control:
-
Constant Bit Rate (CBR), Variable Bit Rate (VBR)
-
Region of Interest (ROI) encoding:
-
Yes
-
Noise reduction technology:
-
3D noise reduction
-
Anti-flicker:
-
Yes
-
Heartbeat:
-
Yes
-
Behavior analysis:
-
Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection
-
User access level:
-
Administrator, Operator, User
-
Password reset via email:
-
Yes
-
Lens viewing angle, horizontal:
-
180
-
Lens viewing angle, vertical:
-
44
