Type:
-
IP security camera
-
Weight:
-
0.77 kg
-
Security algorithms:
-
802.1x RADIUS, EAP-LEAP, EAP-MD5, EAP-TLS
-
Supported network protocols:
-
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets
-
Operating relative humidity (H-H):
-
0 - 95
-
Compatible memory cards:
-
MicroSD (TransFlash), MicroSDHC, MicroSDXC
-
Storage temperature (T-T):
-
-40 - 60
-
Package weight:
-
1053 g
-
Built-in microphone:
-
Yes
-
Operating temperature (T-T):
-
-30 - 60
-
Camera shutter speed:
-
1 - 1/100000
-
Ethernet LAN:
-
Yes
-
Storage relative humidity (H-H):
-
0 - 95
-
Height:
-
67.4 mm
-
Sensor type:
-
CMOS
-
Minimum illumination:
-
0 lx
-
Optical sensor size:
-
25.4 / 3
-
Width:
-
164.3 mm
-
Depth:
-
84.6 mm
-
Connectivity technology:
-
Wired
-
Maximum resolution:
-
2688 x 1520
-
Product colour:
-
White
-
Number of users:
-
32 user(s)
-
Networking standards:
-
IEEE 802.3af
-
LED type:
-
IR
-
Tilt angle range:
-
0 - 60
-
Audio output channels:
-
1.0
-
Video compression formats:
-
H.264, H.265, M-JPEG
-
Bit rate:
-
32 Kbps - 8 Mbps
-
Ethernet LAN (RJ-45) ports:
-
1
-
Angle of rotation:
-
355 °
-
Noise reduction:
-
Yes
-
Pan range:
-
-90 - 90
-
Dynamic range:
-
120 dB
-
Languages support:
-
Multi
-
Progressive scan:
-
Yes
-
Card reader integrated:
-
Yes
-
Placement supported:
-
Indoor & outdoor
-
Mirror:
-
Yes
-
Reset button:
-
Yes
-
Package depth:
-
172 mm
-
Package height:
-
125 mm
-
Package width:
-
227 mm
-
Supported graphics resolutions:
-
640 x 480 (VGA), 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2560 x 1440, 2688 x 1520
-
Supported video modes:
-
480p, 576p, 720p, 1080p, 1440p, 1520p
-
Audio codecs:
-
G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
-
Minimum aperture number:
-
1.2
-
Maximum aperture number:
-
1.6
-
Night vision:
-
Yes
-
Live view:
-
Yes
-
Fixed focal length:
-
2.8 mm
-
Mounting type:
-
Ceiling
-
Video motion detection:
-
Yes
-
Active tampering alarm:
-
Yes
-
IP address filtering:
-
Yes
-
DC output voltage:
-
12
-
DC output current:
-
0.58 A
-
Maximum memory card size:
-
256 GB
-
Number of languages:
-
33
-
Ethernet interface type:
-
Fast Ethernet
-
RS-485 ports:
-
1
-
International Protection (IP) code:
Device protection rating against dust and water according to the international IP standard.
-
IP67
-
Power source type:
-
DC, PoE
-
Total megapixels:
-
4 MP
-
Image quality adjustment:
-
Brightness, Contrast, Saturation, Sharpness
-
Back Light Compensation (BLC):
-
Yes
-
Night vision distance:
-
10
-
Audio input channels:
-
10
-
HTTPS encryption:
-
Yes
-
Wide Dynamic Range (WDR):
-
Yes
-
Infra-red wavelength:
-
850 nm
-
Day/night mode:
-
Yes
-
Alarm input/output:
-
Yes
-
Number of cameras:
-
1
-
Power consumption (max):
-
7 W
-
IK code:
-
IK10
-
Video streaming:
-
Yes
-
Sample rates:
-
8 - 48
-
Password protection:
-
Yes
-
Alarm input channels:
-
1
-
Alarm output channels:
-
1
-
Number of lenses:
-
2
-
Privacy masking:
-
Yes
-
Power consumption (Power over Ethernet (PoE)):
-
9 W
-
Infrared (IR) cut-off filter:
-
Yes
-
Digital watermark:
-
Yes
-
Number of sensors:
-
1
-
Remote viewing:
-
Yes
-
Web browser:
-
Yes
-
Gain control type:
-
Auto
-
Highlight Compensation (HLC):
-
Yes
-
Bit rate control:
-
Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
-
Region of Interest (ROI) encoding:
-
Yes
-
Observe distance:
-
24.2 m
-
Detect distance:
-
61.1 m
-
Recognize distance:
-
12.2 m
-
Identify distance:
-
6.1 m
-
Noise reduction technology:
-
3D noise reduction
-
Heartbeat:
-
Yes
-
Behavior analysis:
-
Audio exception detection, Scene change detection
-
Bit rate range:
-
16 - 64
-
Number of simultaneous live view channels:
-
20 channels
-
User access level:
-
Administrator, Operator, User
-
Password reset via email:
-
Yes
-
Flash log:
-
Yes
-
Digest authentication:
-
Yes
-
Lens viewing angle, horizontal:
-
98.2
-
Lens viewing angle, vertical:
-
54.2
-
Lens viewing angle, diagonal:
-
114.6
-
Compliance certificates:
-
BIS, CB, CE, Electromagnetic Compatibility (EMC), Federal Communications Commission (FCC), Industry Canada (IC), KC, Low Voltage Directive (LVD), RCM, REACH, RoHS, UL, WEEE
