Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
0.35 kg
-
Full duplex:
A full-duplex system allows communication in both directions, and unlike half-duplex, allows this to happen simultaneously.
-
Yes
-
MAC address table:
The MAC address is the 'Media Access Control Address'. It is a unique address given to a network interface controller (NIC) in a device. A MAC address table shows the addresses in a table format.
-
2000 entries
-
Operating relative humidity (H-H):
-
5 - 95
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-40 - 85
-
Package weight:
Weight of the packaged product.
-
915 g
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
-30 - 65
-
Storage relative humidity (H-H):
-
5 - 95
-
Height:
The measurement of the product from head to foot or from base to top.
-
101.2 mm
-
LED indicators:
-
PoE, Power, Link
-
Width:
The measurement or extent of something from side to side.
-
158 mm
-
Depth:
The distance from the front to the back of something.
-
31.6 mm
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Grey
-
Switching capacity:
The data transfer capacity of the switch per second.
-
4.8 Gbit/s
-
Networking standards:
The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
-
IEEE 802.3ab, IEEE 802.3bt, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x, IEEE 802.3at, IEEE 802.3z
-
Power over Ethernet (PoE):
The device supports Power over Ethernet (PoE), which is one of several standardized or ad-hoc systems which pass electrical power along with data on Ethernet cabling. This allows a single cable to provide both data connection and electrical power to devices such as wireless access points or IP cameras.
-
Yes
-
Switch layer:
A network switch is a computer networking device that links networking segments. A switch has different layers, such as layer 2 (a network bridge, operating at the data link layer, interconnecting a small number of devices) and layer 4 (can act as a firewall, amongst other things).
-
L2
-
Input current:
-
1.35
-
Store-and-forward:
-
Yes
-
Switch type:
What switch device has, managed or unmanaged.
-
Unmanaged
-
Gigabit Ethernet (copper) ports quantity:
-
1
-
Housing material:
What the casing of the product is made of.
-
Metal
-
Auto MDI/MDI-X:
A Medium Dependent Interface (MDI) describes the interface (both physical and electrical) in a computer network from a physical layer implementation to the physical medium used to carry the transmission. Ethernet over twisted pair also defines a medium dependent interface crossover (MDIX) interface. Auto-MDIX ports on newer network interfaces detect if the connection would require a crossover, and automatically chooses the MDI or MDIX configuration to properly match the other end of the link.
-
Yes
-
10G support:
The product can use Oracle 10G, which is a database management system introduced in 2003.
-
No
-
Forwarding rate:
-
3.5712 Mpps
-
DC input voltage:
-
48 - 57
-
Power consumption (max):
The maximum amount of power used by the device.
-
65 W
-
Power over Ethernet (PoE) ports quantity:
-
4
-
Basic switching RJ-45 Ethernet ports type:
The type/category of basic switching RJ-45 Ethernet ports (sockets).
-
Fast Ethernet (10/100)
-
Basic switching RJ-45 Ethernet ports quantity:
The number of basic switching RJ-45 Ethernet ports (sockets).
-
3
-
Total Power over Ethernet (PoE) budget:
-
60 W
-
Power over Ethernet (PoE) power per port:
-
60 W
-
Harmonized System (HS) code:
-
85176990
-
SFP module slots quantity:
-
1
-
Fanless:
-
Yes
-
Switching optical modules type:
-
Gigabit Ethernet
