Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
0.12 kg
-
Mean time between failures (MTBF):
Statistical model used to indicate product/mechanism reliability; expressed in hours and percentage of duty cycle. This number (in hours) does not indicate the mean time before failure for a single unit/mechanism.
-
2848397 h
-
Operating relative humidity (H-H):
-
0 - 95
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-40 - 70
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
0 - 60
-
Storage relative humidity (H-H):
-
0 - 95
-
Height:
The measurement of the product from head to foot or from base to top.
-
102 mm
-
LED indicators:
-
Status, Power, Link, Data
-
Width:
The measurement or extent of something from side to side.
-
23 mm
-
Depth:
The distance from the front to the back of something.
-
79 mm
-
Heat dissipation:
The heat generated by the power supply.
-
4.6 BTU/h
-
Input current:
-
0.055
-
Switch type:
What switch device has, managed or unmanaged.
-
Unmanaged
-
Copper ethernet cabling technology:
-
100BASE-TX
-
International Protection (IP) code:
The IP code classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. It is published by the International Electrotechnical Commission (IEC). The digits (characteristic numerals) indicate conformity with the conditions summarized in the tables below. Where there is no protection rating with regard to one of the criteria, the digit is replaced with the letter X. an electrical socket rated IP22 is protected against insertion of fingers and will not be damaged or become unsafe during a specified test in which it is exposed to vertically or nearly vertically dripping water. Another example is the Sony Xperia Z Ultra, one of the first cellular phones to be IP-rated; it is rated at IP58 and marketed as "dust resistant" and can be "immersed in 1.5 meter of freshwater for up to 30 minutes".
-
IP30
-
DC input voltage:
-
9.6 - 32
-
Power consumption (max):
The maximum amount of power used by the device.
-
1.3 W
-
DIN rail mounting:
-
Yes
-
Basic switching RJ-45 Ethernet ports type:
The type/category of basic switching RJ-45 Ethernet ports (sockets).
-
Fast Ethernet (10/100)
-
Basic switching RJ-45 Ethernet ports quantity:
The number of basic switching RJ-45 Ethernet ports (sockets).
-
5
-
Auto-negotiation:
-
Yes
-
Power connector:
-
Terminal block (3-pin)
