Processor frequency:
-
1800 MHz
-
Internal memory:
-
8192 MB
-
Processor model:
-
ARM Cortex-A72
-
Weight:
-
5.1 kg
-
Power consumption (typical):
Power consumption in switched-on state expressed in W.
-
65 W
-
Rack mounting:
-
Yes
-
Flash memory:
-
16384 MB
-
MAC address table:
-
32768 entries
-
Memory type:
-
SDRAM / Flash
-
Operating altitude:
-
0 - 3048
-
Operating relative humidity (H-H):
-
5 - 95
-
Storage temperature (T-T):
-
-40 - 70
-
Form factor:
-
1U
-
Operating temperature (T-T):
-
0 - 45
-
Power source:
-
AC
-
Height:
-
43.9 mm
-
Width:
-
442 mm
-
Depth:
-
327 mm
-
Switching capacity:
-
128 Gbit/s
-
Networking standards:
-
IEEE 802.1s, IEEE 802.3at, IEEE 802.3af, IEEE 802.3ae, IEEE 802.3ad, IEEE 802.3ab, IEEE 802.1w, IEEE 802.1v, IEEE 802.1t, IEEE 802.3az, IEEE 802.1p, IEEE 802.1ak, IEEE 802.1ab, IEEE 802.1Q, IEEE 802.1D, IEEE 802.1AX, IEEE 802.3z, IEEE 802.3x
-
Flow control support:
-
Yes
-
Power over Ethernet (PoE):
-
Yes
-
Switch layer:
-
L3
-
Quality of Service (QoS) support:
-
Yes
-
Port mirroring:
-
Yes
-
Link aggregation:
-
Yes
-
Stackable:
-
Yes
-
Multicast support:
-
Yes
-
Access Control List (ACL):
-
Yes
-
Switch type:
-
Managed
-
IGMP snooping:
-
Yes
-
VLAN support:
-
Yes
-
10G support:
-
Yes
-
Console port:
-
RJ-45/USB Type-C
-
Transmission distance (max):
-
10 km
-
Built-in processor:
-
Yes
-
AC input frequency:
-
50/60
-
AC input voltage:
-
100 - 240
-
Power supply included:
-
Yes
-
Authentication type:
-
TACACS+, RADIUS
-
Basic switching RJ-45 Ethernet ports type:
-
Gigabit Ethernet (10/100/1000)
-
Basic switching RJ-45 Ethernet ports quantity:
-
24
-
Total Power over Ethernet (PoE) budget:
-
370 W
-
Packet buffer memory:
-
8 MB
-
Latency (1 Gbps):
-
2.28 µs
-
Latency (10 Gbps):
-
1.46 µs
-
Throughput:
-
95.2 Mpps
-
Physical stacking (units):
-
8
-
Authentication:
-
Web-based authentication, MAC-based authentication
-
SFP+ module slots quantity:
-
4
