HPE ProLiant ML350 Gen11 Server Intel Xeon Silver 4509Y 2.6GHz 8-Core 64GB DDR5 2x480GB SSD 8SFF Tower 4U

Power supply: The way in which the product is powered e.g. rechargeable battery, mains electricity connected via a plug and cable.

1000 W

Dimensions (W x D x H) (imperial):

304.8 x 584.2 x 984.2

Standard fans:

3x Standard Fans

Maximum internal memory: The maximum internal memory which is available in the product.

8000 GB

Number of HDDs installed: The number of hard drives built into the device.

2

Trusted Platform Module (TPM):

Yes

SSD interface: The type of interface(s) with which the Solid State Drive is connected to other hardware.

SATA III

SSD capacity:

480 GB

Ethernet interface type:

Gigabit Ethernet

Number of SSDs installed:

2

Trusted Platform Module (TPM) version:

2.0

Memory layout (slots x size): The slots and size of the memory for the CPU.

2 x 32

Number of main power supplies: The quantity of main power supplies for this product.

2

Number of redundant power supplies installed:

1

Number of SSDs supported:

8

Supported RAID controllers:

HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller

SSD size:

2.5"

Other features

Storage drive type:

2x HPE 480GB SATA 6G Read Intensive SFF BC Multi Vendor SSD

Expansion slots: List of I/O expansion card slots; including quantity of each

2 to 10 PCIe Gen5 (2 OCP 3.0). Refer to the QuickSpecs for more detail.

Security features:

UEFI Secure Boot and Secure Start support. Intel Software Guard Extensions (SGX) support. Immutable Silicon Root of Trust. TPM (Trusted Platform Module) 2.0 support. Front bezel key-lock feature, Intrusion Cable (Optional), Padlock slot and Kensington Lock slot support.

Power supply type: The type of power supply which this product uses.

2x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit

Management platform:

HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download); HPE iLO Advanced, HPE OneView Advanced (require licenses), and HPE Compute Ops Management.

Technical details

Total storage capacity: The total amount of data that can be stored on the device.

960 GB

Weight & dimensions

Weight (imperial):

95.372 lbs

Weight: Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.

43.26 kg

Height: The measurement of the product from head to foot or from base to top.

984.3 mm

Depth: The distance from the front to the back of something.

584.2 mm

Width: The measurement or extent of something from side to side.

304.8 mm

Power

Redundant power supply (RPS) support: Additional power supply which can run a computer if the main power supply fails.

Yes

Software

Operating system installed: Type of operating system on a device e.g. IOS on Apple devices, Android for mobile devices.

No

Performance

Optical drive type: An optical drive uses laser to read optical discs such as CDs, DVDs and Blu-Ray. Some types of optical drive are: CD ROM drive, CR-RW (CD writer) drive, DVD-ROM.

No

Design

Product colour: The colour e.g. red, blue, green, black, white.

Black

Chassis type: The type of rigid framework onto which is the hosuing for device components.

Tower (4U)

Ports & interfaces

Ethernet LAN (RJ-45) ports: Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.

4

Network

LAN controller:

Broadcom BCM5719

Ethernet LAN: An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.

Yes

Memory

Memory slots: Number and type of memory expansion slots, including connector and memory module descriptions.

32x DIMM

Memory clock speed: The frequency at which the memory (e.g. RAM) runs.

5600 MHz

Internal memory type: The type of internal memory such as RAM, GDDR5.

DDR5-SDRAM

Internal memory: A computer's memory which is directly accessible to the CPU.

64 GB

Processor

Number of processors installed: Number of processors in the product.

1

Number of processors supported: The quantity of processors which can be used by the product.

1

Processor cache type:

L3

Processor cache:

22.5 MB

Processor cores: The number of central processing units ('cores') in a processor. Some processors have 1 core, others have 2 (e.g. Intel Core Duo) or more (e.g. the Intel Xeon E7-2850 has 10 cores).

8

Processor boost frequency: The turbo boost is an automatic, managed accelleration of the processor when one of the cores is overloaded.

4.1 GHz

Processor frequency: The speed that the microprocessor executes each instruction or each vibration of the clock. The CPU requires a fixed number of clock ticks, or cycles, to execute each instruction. The faster the clocks rate, the faster the CPU, or the faster it can execute instructions. Clock Speeds are usually determined in MHz, 1 MHz representing 1 million cycles per second, or in GHz, 1 GHz representing 1 thousand million cycles per second. The higher the CPU speed, the better a computer will perform.

2.6 GHz

Processor model: The model number for the processor in a computer.

4509Y

Processor family: A family of processors is a group of processors produced by one company over a short period of time e.g. Intel Pentium processors.

Intel Xeon Silver

Processor manufacturer: The manufacturer that produced the processor.

Intel

Storage

RAID support: The device uses RAID, which is a storage technology that combines multiple disk drive components into a logical unit for the purposes of data redundancy and performance improvement. Data is distributed across the drives in one of several ways, referred to as RAID levels, depending on the specific level of redundancy and performance required.

Yes
