Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
21 kg
-
Safety:
List of regulatory safety standards for all countries in which this product has been certified.
-
EN/IEC62109-1, EN/IEC62109-2
-
Operating altitude:
-
0 - 4000
-
Operating relative humidity (H-H):
-
0 - 100
-
Compatibility:
The other products, software and hardware this product can be used with.
-
LUNA2000-5/10/15-S0 / LUNA2000-7/14/21-S1
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
-25 - 60
-
Height:
The measurement of the product from head to foot or from base to top.
-
130 mm
-
LED indicators:
-
Y
-
Width:
The measurement or extent of something from side to side.
-
490 mm
-
Depth:
The distance from the front to the back of something.
-
460 mm
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
White
-
Noise level:
The amplitude level of the undesired background noise, usually measured in decibels (db).
-
29 dB
-
Total Harmonic Distortion (THD):
Total harmonic distortion is a measure of non-linear harmonic
distortion and is given in %. Non-linear harmonic distortions are
signals which were not present in the original before the signal was
converted by the headphones. These unwanted signals are caused by the
diaphragm, whose movements do not precisely move in time with the
electric signals that cause it to move. Unfortunately, this is a
feature of all electroacoustic transducers. Although it cannot be
completely eliminated, suitable steps can be taken to minimise it.
However, the user is not interested in why this distortion takes place
but in how great the level of distortion must be for it to become
perceptible. According to the findings of several research projects, a
total harmonic distortion of 1% in the frequency range of 100 to 2000
Hz is imperceptible. Below 100 Hz, the perceptibility threshold lies
at 10%.
-
3 %
-
Wi-Fi:
Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.
-
Yes
-
Output current:
-
16.7 A
-
Efficiency:
-
98.6 %
-
Power protection features:
Features that protect the device against power problems e.g. overload.
-
Short circuit, Reverse polarity, Surge protection, Over current, Over voltage
-
Number of phases:
-
3
-
Power factor:
-
0.8
-
International Protection (IP) code:
The IP code classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. It is published by the International Electrotechnical Commission (IEC). The digits (characteristic numerals) indicate conformity with the conditions summarized in the tables below. Where there is no protection rating with regard to one of the criteria, the digit is replaced with the letter X. an electrical socket rated IP22 is protected against insertion of fingers and will not be damaged or become unsafe during a specified test in which it is exposed to vertically or nearly vertically dripping water. Another example is the Sony Xperia Z Ultra, one of the first cellular phones to be IP-rated; it is rated at IP58 and marketed as "dust resistant" and can be "immersed in 1.5 meter of freshwater for up to 30 minutes".
-
IP66
-
Output operation voltage (min):
The minumum voltage produced by the device during operation.
-
220 V
-
Output operation voltage (max):
The maximum output voltage produced by the device.
-
415 V
-
DC input voltage:
-
600 - 980
-
Output frequency:
-
50/60
-
Product type:
The sub-category of the product.
-
Intelligent hybrid inverter
-
Output power capacity (max):
-
11 kVA
-
Discharge power:
-
11000 W
-
Starting voltage:
-
160 V
-
Maximum input current per MPPT:
-
16 A
-
Photovoltaic (PV) charging supported:
-
Yes
-
Maximum input power (DC):
-
12000 W
-
Short-circuit current per MPPT (max):
-
22 A
-
Efficiency (EU):
-
98.1 %
