Internal memory:
-
2048 MB
-
Weight:
-
2.94 kg
-
Power consumption (typical):
Power consumption in switched-on state expressed in W.
-
44.09 W
-
Rack mounting:
-
Yes
-
Mean time between failures (MTBF):
-
517978.8 h
-
Flash memory:
-
1000 MB
-
Operating altitude:
-
0 - 5000
-
Operating relative humidity (H-H):
-
5 - 95
-
Storage temperature (T-T):
-
-40 - 70
-
Package weight:
-
3810 g
-
Form factor:
-
1U
-
Operating temperature (T-T):
-
-5 - 50
-
Power source:
-
AC
-
Non-operating altitude:
-
0 - 5000
-
Height:
-
43.6 mm
-
LED indicators:
-
Y
-
Routing protocols:
-
OSPFv3, OSPF, RIP-1, RIP-2, RIPng
-
Width:
-
442 mm
-
Depth:
-
220 mm
-
Product colour:
-
Black, Silver
-
Noise level:
Not only energy saving helps to protect the environment but also noise level reduction. Noise level reduction up to 3 dB really means noise level reduction in 2 times. For example, a device with noise level 39 dB (А) will be two times quieter than a devise with a noise level 42 dB (А). Energy-saving certificate that shows noise level plays the role of an additional objective indicator basing on which You can successfully choose a product.
-
37.3 dB
-
Switching capacity:
-
176 Gbit/s
-
Networking standards:
-
IEEE 802.1x
-
Heat dissipation:
-
150.44 BTU/h
-
USB 2.0 ports quantity:
-
1
-
Power over Ethernet (PoE):
-
Yes
-
Switch layer:
-
L3
-
Quality of Service (QoS) support:
-
Yes
-
Access Control List (ACL):
-
Yes
-
IP routing:
-
Yes
-
Switch type:
-
Managed
-
Package depth:
-
360 mm
-
Package height:
-
90 mm
-
Package width:
-
550 mm
-
Number of VLANs:
-
4094
-
VLAN support:
-
Yes
-
10G support:
-
Yes
-
Console port:
-
RJ-45
-
Forwarding rate:
-
132 Mpps
-
AC input frequency:
-
50 - 60
-
AC input voltage:
-
100 - 240
-
Power consumption (max):
-
59.15 W
-
Power supply included:
-
Yes
-
Basic switching RJ-45 Ethernet ports type:
-
Gigabit Ethernet (10/100/1000)
-
Basic switching RJ-45 Ethernet ports quantity:
-
24
-
Total Power over Ethernet (PoE) budget:
-
400 W
-
MAC address auto-learning supported:
-
Yes
-
MAC address auto-aging supported:
-
Yes
-
SFP+ module slots quantity:
-
4
-
Static route:
-
Yes
-
Airflow direction:
-
Side-to-side airflow
-
MAC address entries:
-
Static MAC address entries, Dynamic MAC address entries, Blackhole MAC address entries
-
Virtual LAN features:
-
Policy-based VLAN, Voice VLAN, Protocol-based VLAN, Port-based VLAN, Multiple VXLAN (MUX VLAN), MAC address-based VLAN, IP subnet–based VLAN
