Internal memory:
The amount of memory, usually measured in bytes (e.g. MB, GB), which is installed in the system's hardware.
-
2048 MB
-
Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
2.94 kg
-
Power consumption (typical):
Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.
-
44.09 W
-
Rack mounting:
The type of mounting that can position devices in a shelving system (rack).
-
Yes
-
Mean time between failures (MTBF):
Statistical model used to indicate product/mechanism reliability; expressed in hours and percentage of duty cycle. This number (in hours) does not indicate the mean time before failure for a single unit/mechanism.
-
517978.8 h
-
Flash memory:
-
1000 MB
-
Operating altitude:
-
0 - 5000
-
Operating relative humidity (H-H):
-
5 - 95
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-40 - 70
-
Package weight:
Weight of the packaged product.
-
3810 g
-
Form factor:
The shape or design of the product.
-
1U
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
-5 - 50
-
Power source:
What is providing power for the product e.g. mains electricity.
-
AC
-
Non-operating altitude:
-
0 - 5000
-
Height:
The measurement of the product from head to foot or from base to top.
-
43.6 mm
-
LED indicators:
-
Y
-
Routing protocols:
-
OSPFv3, OSPF, RIP-1, RIP-2, RIPng
-
Width:
The measurement or extent of something from side to side.
-
442 mm
-
Depth:
The distance from the front to the back of something.
-
220 mm
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Black, Silver
-
Noise level:
The amplitude level of the undesired background noise, usually measured in decibels (db).
-
37.3 dB
-
Switching capacity:
The data transfer capacity of the switch per second.
-
176 Gbit/s
-
Networking standards:
The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
-
IEEE 802.1x
-
Heat dissipation:
The heat generated by the power supply.
-
150.44 BTU/h
-
USB 2.0 ports quantity:
Number of USB 2.0 ports (connecting interfaces) in the device. USB 2.0 was released in April 2000 (now called "Hi-Speed"), adding higher maximum signaling rate of 480 Mbit/s (effective throughput up to 35 MB/s or 280 Mbit/s), USB 2.0 ports are usually black.
-
1
-
Power over Ethernet (PoE):
The device supports Power over Ethernet (PoE), which is one of several standardized or ad-hoc systems which pass electrical power along with data on Ethernet cabling. This allows a single cable to provide both data connection and electrical power to devices such as wireless access points or IP cameras.
-
Yes
-
Switch layer:
A network switch is a computer networking device that links networking segments. A switch has different layers, such as layer 2 (a network bridge, operating at the data link layer, interconnecting a small number of devices) and layer 4 (can act as a firewall, amongst other things).
-
L3
-
Quality of Service (QoS) support:
-
Yes
-
Access Control List (ACL):
-
Yes
-
IP routing:
-
Yes
-
Switch type:
What switch device has, managed or unmanaged.
-
Managed
-
Package depth:
The distance from the front to the back of the packaging.
-
360 mm
-
Package height:
The distance from the top to the bottom of the packaging.
-
90 mm
-
Package width:
The distance from one side of the packaging to the other.
-
550 mm
-
Number of VLANs:
-
4094
-
VLAN support:
A Virtual Local Area Network (VLAN) consists of a group of computers and switches that can be physically distributed over different networks and buildings, but form one LAN on a logical level.
-
Yes
-
10G support:
The product can use Oracle 10G, which is a database management system introduced in 2003.
-
Yes
-
Console port:
-
RJ-45
-
Forwarding rate:
-
132 Mpps
-
AC input frequency:
-
50 - 60
-
AC input voltage:
The voltage of the AC electricity that is inputted into the product.
-
100 - 240
-
Power consumption (max):
The maximum amount of power used by the device.
-
59.15 W
-
Power supply included:
There is a power supply with this product.
-
Yes
-
Basic switching RJ-45 Ethernet ports type:
The type/category of basic switching RJ-45 Ethernet ports (sockets).
-
Gigabit Ethernet (10/100/1000)
-
Basic switching RJ-45 Ethernet ports quantity:
The number of basic switching RJ-45 Ethernet ports (sockets).
-
24
-
Total Power over Ethernet (PoE) budget:
-
400 W
-
MAC address auto-learning supported:
-
Yes
-
MAC address auto-aging supported:
-
Yes
-
SFP+ module slots quantity:
-
4
-
Static route:
-
Yes
-
Airflow direction:
-
Side-to-side airflow
-
MAC address entries:
-
Static MAC address entries, Dynamic MAC address entries, Blackhole MAC address entries
-
Virtual LAN features:
-
Policy-based VLAN, Voice VLAN, Protocol-based VLAN, Port-based VLAN, Multiple VXLAN (MUX VLAN), MAC address-based VLAN, IP subnet–based VLAN
