Type:
-
IP security camera
-
Optical zoom:
-
30 x
-
Weight:
-
3 kg
-
Certification:
-
UL (UL62368-1), c-UL (CSA C22.2 No.62368-1), CE, IEC62368-1, FCC (Part15 ClassA), ICES-003 Issue 7 ClassA, EN55032 ClassA, EN55035
-
Security algorithms:
-
FIPS 140-2
-
Zoom capability:
-
Yes
-
Supported network protocols:
-
IPv6 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, SMTP, DNS, NTP, SNMPv1/v2/v3, DHCPv6, RTP, MLD, ICMP, ARP, IEEE 802.1X, DiffServ IPv4 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, RTSP, RTP, RTP/RTCP, SMTP, DHCP, DNS, DDNS, NTP, SNMPv1/v2/v3, UPnP, IGMP, ICMP, ARP, IEEE 802.1X, DiffServ, SRTP, MQTT, NTCIP
-
White balance:
-
ATW, AWC
-
Operating relative humidity (H-H):
-
10 - 100
-
Compatible memory cards:
-
MicroSD (TransFlash), MicroSDHC, MicroSDXC
-
Focus:
-
Motorized
-
Form factor:
-
Dome
-
Operating temperature (T-T):
-
-50 - 60
-
Camera shutter speed:
-
16/25 - 1/10000
-
Ethernet LAN:
-
Yes
-
Height:
-
205 mm
-
Focal length range:
-
4.25 - 135
-
Sensor type:
-
CMOS
-
Image stabilizer:
-
Yes
-
Minimum illumination:
-
0.1 lx
-
Optical sensor size:
-
25.4 / 2.8
-
Width:
-
167 mm
-
Depth:
-
167 mm
-
Connectivity technology:
-
Wired
-
Maximum resolution:
-
3328 x 1872
-
Product colour:
-
Black
-
Number of users:
-
14 user(s)
-
Networking standards:
-
IEEE 802.3bt
-
Tilt angle range:
-
-20 - 90
-
Audio formats supported:
-
AAC-LC, G.711, G.726
-
Ethernet LAN (RJ-45) ports:
-
1
-
Microphone in:
-
Yes
-
Noise reduction:
-
Yes
-
Closest focusing distance:
-
3 m
-
Pan range:
-
0 - 360
-
Pan speed:
-
700 °/sec
-
Tilt speed:
-
150 °/sec
-
Dynamic range:
-
132 dB
-
Languages support:
-
DEU, ENG, ESP, FRE, ITA, JPN, POR, RUS
-
Card reader integrated:
-
Yes
-
Placement supported:
-
Outdoor
-
Frame rate:
-
30 fps
-
Supported graphics resolutions:
-
320 x 180, 640 x 360, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2560 x 1440
-
Housing material:
-
Aluminium, Polycarbonate (PC), Stainless steel
-
Minimum aperture number:
-
1.6
-
Maximum aperture number:
-
4.7
-
Night vision:
-
Yes
-
Power consumption:
-
850 mA
-
Mounting type:
-
Ceiling
-
Video motion detection:
-
Yes
-
Audio detection:
-
Yes
-
Video formats supported:
-
H.264, H.265, M-JPEG
-
Maximum memory card size:
-
512 GB
-
Number of languages:
-
9
-
Ethernet interface type:
-
Fast Ethernet
-
PTZ control:
-
Yes
-
International Protection (IP) code:
Device protection rating against dust and water according to the international IP standard.
-
IP66
-
Power source type:
-
PoE
-
Total megapixels:
-
6 MP
-
Back Light Compensation (BLC):
-
Yes
-
Protection features:
-
Tamper resistant, Wind resistant
-
Night vision distance:
-
280
-
Auto-tracking:
-
Yes
-
HTTPS encryption:
-
Yes
-
Alarm input/output:
-
Yes
-
Number of cameras:
-
1
-
Mobile operating systems supported:
-
iOS 8.0
-
Fog proof:
-
Yes
-
IK code:
-
IK10
-
Number of lenses:
-
1
-
Preset points:
-
Yes
-
Auto pan mode:
-
Yes
-
Auto patrol mode:
-
Yes
-
Privacy masking:
-
Yes
-
Text caption overlay:
-
Yes
-
Power consumption (Power over Ethernet (PoE)):
-
45.9 W
-
Alert notification type:
-
E-mail
-
PTZ modes:
-
Auto pan, Preset point
-
Number of sensors:
-
1
-
Web browser:
-
Yes
-
Gain control type:
-
Auto
-
Detect distance (wide):
-
110.8 m
-
Detect distance (tele):
-
3050.4 m
-
Observe distance (wide):
-
44.3 m
-
Observe distance (tele):
-
1220.2 m
-
Recognize distance (wide):
-
22.2 m
-
Recognize distance (tele):
-
610.1 m
-
Identify distance (wide):
-
11.1 m
-
Identify distance (tele):
-
305 m
-
Intelligent Video Surveillance (IVS) system features:
-
Face detection, Scene change, Vehicle detection
-
Highlight Compensation (HLC):
-
Yes
-
Bit rate control:
-
Constant Bit Rate (CBR), Variable Bit Rate (VBR)
-
Tilt preset speed:
-
500 °/sec
-
Number of effective pixels (H x V):
-
5.57 x 3.13
-
Camera tilt control:
-
Yes
-
Bit rate range:
-
16 - 128
-
Digest authentication:
-
Yes
-
Lens viewing angle, horizontal:
-
2.5 - 62
-
Lens viewing angle, vertical:
-
1.4 - 37
-
Number of Privacy masking areas:
-
32
-
Compliance certificates:
-
National Defense Authorization Act (NDAA)
