InLine 69927W Cable Coupler Black Polyamide Silicone IP68 3-Pin M20 TÜV RoHS

The InLine 69927W cable coupler in black is a high-quality, durable solution designed for secure and waterproof electrical connections in demanding environments. Manufactured from robust polyamide and flexible silicone, this 3-pin M20 connector provides exceptional reliability for both professional and domestic wiring installations. Featuring IP68 protection, it ensures complete safety against water, dust, and harsh weather conditions, making it an essential component for dependable power transmission.

Advantages

This cable coupler delivers outstanding performance thanks to its gold-plated copper contacts, which minimize contact resistance, protect against corrosion, and guarantee high conductivity even with frequent use. The robust housing withstands extreme temperatures ranging from -40 °C to +105 °C. An easy installation process with a snap-lock screw system allows for quick, tool-free setup and dismantling, offering high flexibility for various electrical setups.

Suitable for

• Outdoor lighting and garden installations
• Water pump systems and irrigation setups
• Temporary or mobile power supplies and campsites
• Industrial and domestic control line wiring
• Connecting 3-wire fine cables with diameters from 4 to 14 mm

When it may not be suitable

This cable coupler is not designed for high-voltage industrial power transmission exceeding its rated voltage of 500 V or rated current of 20 A. It may also not be suitable for cables with cross-sections outside the specified 0.5 to 6 mm² range or diameters smaller than 4 mm or larger than 14 mm.

Key specifications

• Product type: 3-pin cable coupler with plug and socket system
• Colour: Black
• Material: Polyamide and silicone seal
• Thread size: M20
• IP protection rating: IP68
• Rated voltage: 500 V
• Rated current: 20 A
• Cable diameter range: 4–14 mm
• Conductor cross-section: 0.5–6 mm²
• Operating temperature range: -40 °C to +105 °C
• Certificates: TÜV and RoHS compliant

How to use

To use the InLine cable coupler, prepare your 3-wire cable by stripping the outer insulation to fit the internal terminals. Insert the cable through the M20 threaded sealing cap into the connector housing. Connect the individual wires securely to the 3-pin contacts. Ensure the silicone seal is correctly positioned to maintain the waterproof rating. Tighten the screw cap firmly to lock the cable in place, and use the snap-lock mechanism to connect the plug and socket components together securely.

What to consider before purchase

• Verify that your cable diameter falls within the 4 mm to 14 mm range.
• Check that your conductor cross-section does not exceed 6 mm².
• Ensure your electrical load requirements are within the 500 V and 20 A limits.
• Confirm whether a detachable 3-pin IP68 connection is required for your specific application.

Usage recommendations

For optimal safety and longevity, always ensure that the screw caps and silicone seals are tightened correctly during installation to maintain the IP68 waterproof rating. Periodically inspect the gold-plated contacts and housing for any signs of wear if the connector is used in frequent mobile disconnection cycles.
