InLine RJ45 Keystone Jack Snap-In Module Cat.6a with Dust Cover Blue Flat RJ-45 10GBase-T

The InLine RJ45 Keystone Jack Snap-In Module Cat.6a with Dust Cover Blue Flat RJ-45 10GBase-T is a high-performance network accessory designed for professional structured cabling systems. Featuring a flat construction design and a protective blue dust cover, this fully shielded module ensures stable and reliable data transmission for modern network installations. It is engineered to support demanding 10GBase-T network connections and is built with a durable zinc alloy housing to deliver consistent performance in patch panels and wall outlets.

Advantages

This Keystone module offers full shielding to protect data signals from electromagnetic interference, ensuring a secure and stable network environment. The integration of LSA mount technology allows for secure and efficient cable termination. Additionally, support for Power over Ethernet standards such as PoE and PoE+ makes it versatile for powering network devices directly through the cabling infrastructure. The included blue dust cover helps protect the female RJ-45 connector from dust and debris when not in use, extending the lifespan of the connection.

Suitable for

• Building structured cabling systems in homes, offices, and data centers
• Connecting 19-inch empty patch panels and wall boxes for keystone applications
• Network installations requiring Cat.6a performance up to 10Gb/s and 500MHz
• Deployments utilizing 22AWG to 26AWG network cables with an outer diameter between 5.0mm and 8.5mm
• Setups that require Power over Ethernet (PoE and PoE+) support

When it may not be suitable

This module may not be suitable for cables with wire gauges outside the 22AWG to 26AWG range or outer diameters that fall outside the 5.0mm to 8.5mm specification. It is also not designed for non-keystone standard faceplates or modular panels that do not follow the standard Keystone snap-in dimensions.

Key specifications

• Cat.6a performance supporting up to 10Gb/s and 500MHz
• Flat construction design with grey housing and blue dust cover
• RJ-45 female connector with full shielding
• Zinc alloy housing material
• Compatible with cable sizes 22AWG to 26AWG and outer diameters 5.0mm to 8.5mm
• LSA mount termination
• Supports PoE and PoE+
• Minimum contact durability of 750 mating cycles

How to use

To install the module, prepare the network cable by stripping the outer jacket to expose the individual conductors. Sort the wires according to the required T568A or T568B wiring standard and press them into the LSA terminals using a punch-down tool. Snap the fully shielded Keystone module securely into a compatible 19-inch empty patch panel or wall box cutout. Ensure the dust cover is positioned correctly to protect the RJ-45 port when the patch cable is disconnected.

What to consider before purchase

• Verify that your patch panel or wall outlet supports standard Keystone snap-in dimensions
• Check that your network cables match the 22AWG to 26AWG gauge and 5.0mm to 8.5mm outer diameter requirements
• Confirm whether your network setup requires Cat.6a performance and 10GBase-T support

Usage recommendations: For optimal network performance, ensure proper cable management and avoid exceeding the recommended bending radii during installation. Maintain correct twist rates up to the LSA termination point to preserve signal integrity in high-speed 10GBase-T environments.
