Internal USB Type-C Adapter InLine 76660I

Name: Internal USB Type-C Adapter InLine 76660I
Brand: InLine
SKU: 11431725
Price: 62.99 EUR
Availability: InStock

EcoFlow – energy without limits

Powerful EcoFlow stations for energy anywhere!

Internal USB Type-C Adapter InLine 76660I PCIe 20 Gbit/s

Internal USB Type-C Adapter InLine 76660I Photo 1

Internal USB Type-C Adapter InLine 76660I Photo 2

Internal USB Type-C Adapter InLine 76660I Photo 3

Internal USB Type-C Adapter InLine 76660I Photo 4

Internal USB Type-C Adapter InLine 76660I Photo 5

Internal USB Type-C Adapter InLine 76660I Photo 6

Internal USB Type-C Adapter InLine 76660I Photo 7

Internal USB Type-C Adapter InLine 76660I Photo 8

Internal USB Type-C Adapter InLine 76660I Photo 9

Keep track of price changes You keep track of price changes

Scan qr code below, or type in manually: {{secretKey}}

Forgot password? Registration

Offer for legal entity, cashless payment. Why is an item available only for a legal entity?
This is due to long delivery times and limited product warranties.

Short description

The InLine 76660I is an internal USB Type-C adapter featuring PCIe host interface and a maximum data transfer rate of 20 Gbit/s. It supports various operating systems including Windows and Mac, making it versatile for different setups. The adapter provides 5V output voltage and 3A output current, ensuring efficient power delivery for connected devices.

Available for order: 100 pcs.

Warranty: 2 Years

SKU: 11431725

Learn more

Cheapest delivery:

Unisend LV

Pick-up points

Unisend LV

Cost

1.99 €

Deliver

All delivery methods Hide details

Customer service center

2b. Kengaraga str., Riga, Latvia, LV-1063

27.10.2026 {{selectedOffer.officeDeliveryString}}

free

Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!

30.10.2026 {{selectedOffer.courierDeliveryString}}

From 4.99 € (Weight: 1.00 kg)

Parcel couriers

Unisend LV / Venipak Pickup LV / Venipak Locker LV / DPD Paku skapis / Omniva LV / Latvijas Pasts pakomāts / Latvijas Pasts nodaļa

30.10.2026 {{selectedOffer.parcelStationDeliveryString}}

From 1.99 €

More about delivery methods

Payment Methods:

Bank transfer

More about payment methods

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The InLine 76660I is an internal USB Type-C adapter that adds a high-performance USB-C port to a desktop PC via a PCIe 3.0 x4 slot. It implements the USB 3.2 Gen 2x2 standard and ASMedia ASM3242 chipset to deliver data transfer speeds up to 20 Gb/s, making it suitable for fast external storage, NVMe enclosures and other high-bandwidth peripherals. The card is low-profile, provides up to 5 V/3 A power via the USB-C port and supports Plug & Play operation without additional drivers.

Advantages

The adapter offers very high transfer rates (up to 20 Gb/s) and broad compatibility with x4, x8 and x16 PCIe slots. Built on the ASMedia ASM3242 chipset, it supports UASP for optimized data throughput, includes overcurrent protection and is backward compatible with older USB standards. Its low-profile form factor and included bracket make it easy to install in a variety of PC cases.

Suitable for

High-speed external storage (NVMe enclosures, SSD docking stations)
Backup and large file transfers
High-performance USB-C peripherals requiring up to 5 V/3 A power
Upgrading desktops to add modern USB-C connectivity

Key specifications

Host interface: PCIe 3.0 x4 (compatible with x4, x8, x16 slots)
USB standard: USB 3.2 Gen 2x2 (SuperSpeed 20 Gb/s) — also supports 10 Gb/s, 5 Gb/s and 480 Mb/s
Chipset: ASMedia ASM3242
Power via USB-C: up to 5 V / 3 A
Form factor: Low profile; PCB dimensions 79 mm x 51 mm
Operating systems: Windows 7/8/10/11, Windows Server (2008 R2, 2016, 2019, 2021), Linux (kernel ≥ 2.6.30), macOS 10.8+
Environmental: Operating temp 0 °C to 85 °C; storage temp -25 °C to 85 °C; max humidity 90%

How to use

Install the card into an available PCIe x4 (or x8/x16) slot on the motherboard, secure the low-profile bracket if needed and connect the USB-C device to the rear port. The card supports Plug & Play so no additional drivers are typically required; ensure the system BIOS and operating system are up to date and that connected devices are compatible with USB 3.2 Gen 2x2 or lower speeds as supported.

Usage recommendations

For optimal performance, use high-quality USB-C cables and connect NVMe or high-speed external drives that support UASP. If you require continuous high power delivery, verify the connected device’s power needs do not exceed the card’s 5 V/3 A specification and ensure adequate case ventilation to stay within the specified operating temperature range.

Specifications

Internal: The product is built in.: Yes
Host interface: Interface that enables a host controller to communicate with a driver.: PCIe
Output interface: The socket (port) where the output connectors are connected.: USB Type-C

All features

Weight & dimensions

Weight: Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.: 0.035 kg
Depth: The distance from the front to the back of something.: 51 mm
Width: The measurement or extent of something from side to side.: 79 mm

Operational conditions

Operating relative humidity (H-H):: 0 - 90
Storage temperature (T-T): The minimum and maximum temperatures at which the product can be safely stored.: -25 - 85
Operating temperature (T-T): The minimum and maximum temperatures at which the product can be safely operated.: 0 - 85

System requirements

Server operating systems supported:: Windows Server 2019, Windows Server 2016, Windows Server 2008 R2
Linux operating systems supported: 8 RT. Linux (9.4, 9.5), Red Hat Enterprise Linux 5.0 (supported with a pre-built package); SUSE Linux (10.3, 11.0, 11, 11.1, 11.2), Fedora (9, 9.0, 10, 10.0, 11.0, 11, 12, 12.0), Ubuntu (8.04, 8.04.1, 8.04.2, 8.10, 9.04, 9.10, 10.04), Debian (5.0, 5.0.1, 5.0.2, 5.0.3): Kernel 2.6.31, Linux Kernel 5.15, Kernel 2.6.33, Kernel 3.12, Kernel 3.17, Kernel 3.3, Kernel 4.6.4, Linux Kernel 5.10, Linux Kernel 5.11, Linux Kernel 5.12, Linux Kernel 5.13, Linux Kernel 5.14, Linux Kernel 6.2, Linux Kernel 5.9, Linux Kernel 5.8, Linux Kernel 5.19, Linux Kernel 5.4
Mac operating systems supported: Mac operating systems e.g. OS X can be used with the device.: Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura, Mac OS X 14.0 Sonoma, Mac OS X 10.8 Mountain Lion
Windows operating systems supported: Windows vesions wich can be used with the device.: Windows 10, Windows 11, Windows 7, Windows 8

Other features

Manual:: Yes

Logistics data

Country of origin: Country where the device is made. Aka Country of manufacture (COM).: Taiwan

Packaging data

Package type: The type of product package e.g. box.: Hanging box
Mounting brackets included:: Yes

Technical details

Compliance certificates: Indicates which regulatory, safety, and environmental standards the product complies with, as verified by recognized authorities or certification bodies.: TÜV mark, Federal Communications Commission (FCC), CE

Power

Output current:: 3 A
Output voltage:: 5

Features

Plug and Play: Indicates whether this product supports is "plug and play". Plug and play is hardware or software that, after being installed ("plugged in"), can immediately be used ("played with"), as opposed to hardware or software which requires configuration.: Yes
UASP support:: Yes
Data transfer rate (max):: 20 Gbit/s
Connector 1 gender: The gender of the first connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the part bearing one or which fits into another being called male.: Female

Design

Internal: The product is built in.: Yes

Ports & interfaces

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: Number of USB 3.1 (3.1 Gen 2) ports with Type-C connector. USB 3.1 (3.1 Gen 2) is USB interface version which supports transfer rate up to 10 Gbit/s (SuperSpeed+). USB Type-C connector has symmetrical design architecture and compatible with Thunderbolt 3 interface.: 1
Expansion card standard:: PCIe 3.0
Expansion card form factor:: Low-profile
Host interface gender:: Male
Host interface: Interface that enables a host controller to communicate with a driver.: PCIe
Output interface: The socket (port) where the output connectors are connected.: USB Type-C

Performance

Chipset: Set of electronic components in an integrated circuit that manages the data flow between the processor, memory and peripherals. It is usually found in the motherboard of a computer. Chipsets are usually designed to work with a specific family of microprocessors. Because it controls communications between the processor and external devices, the chipset plays a crucial role in determining system performance.: ASMedia ASM3242

Hide Show all

Description

Machine translation. Load original

Show details Hide details

{{highlightedFeature.featureTitle}}:

{{getProductFeatureValueById(product, highlightedFeature.featureId)}}

Customer reviews

Show all reviews

Customer questions

FAQ

How much does the Internal USB Type-C Adapter InLine 76660I cost, and is it available for purchase?

The price is 62.99 € (valid at the time of publication and already includes all taxes). The item is available for order — 100 pcs. are in stock, and you can place your purchase right now with delivery across Latvia and Europe or choose pickup at the Riga collection point. We offer favorable purchase terms, including the option to split the payment into convenient monthly installments. Availability and price are updated in real time, so we recommend placing your order in advance.

If I order this product today, when will I receive my order?

If you place your order today, delivery will be as fast and convenient as possible. You will be able to pick up your order on 27.10.2026 at the Riga pickup point or choose delivery across Latvia and Europe. We carefully inspect every purchase and pack it securely for safe transportation.

What payment options are available?

AiO.lv offers several payment methods: Bank transfer. All transactions are 100% secure and encrypted.

Can this product be purchased for a company (with VAT)?

Yes. AiO.lv works with legal entities in Latvia and across Europe. The product price already includes VAT. For certain product categories, as well as for companies from other EU countries with a valid VAT number, a 0% VAT rate may apply. We issue the invoice immediately after the order is placed, support electronic BIS invoices, and automatically generate all necessary accounting documents. You can complete the purchase for a company online — simply select the company profile and choose bank transfer as the payment method during checkout.

What is the warranty period?

All InLine products come with an official 2 Years warranty. It covers all manufacturing defects and malfunctions that may occur during use. The warranty is valid at all authorized InLine service centers and through AiO.lv

Can the product be returned after purchase?

Yes, you can return the product within 14 days of purchase if you bought it as a consumer (not a legal entity). Returns are possible without giving any reason — the main condition is that the product retains its original appearance and full set of accessories. We will make the process as simple and convenient as possible: just contact our customer support team, and we will help you arrange the return.

Where should I contact for warranty service?

For warranty-related questions you can contact the AiO.lv (SIA VSPRO) customer support team. We will assist with consultation, warranty claim processing, and coordination with certified service centers.

How can I tell if this product suits my needs?

When making a choice, we recommend paying attention to the key features: internal, host interface, output interface, compatibility with your devices or usage conditions, material quality, functionality, and warranty terms. These characteristics will help you determine how well the model meets your needs.
