InLine 92504E USB-C to 5-pin Terminal Block Cable Male to Female Black and Green

The InLine 92504E USB-C to 5-pin Terminal Block Cable features a USB-C male connector on one end and a 5-pin terminal block female interface on the other, connected by a 1-meter cable. This wire connector is designed for secure wiring and reliable signal transmission in electronic setups, prototyping, and industrial or DIY electrical applications. Built to RoHS and TÜV compliance standards, the adapter combines black and green colors for clear identification and easy integration into existing workspaces.

Advantages

This adapter saves significant time during installation by allowing quick wiring via screw terminals for 16 to 26 AWG wires, which is easily managed with a flat-head screwdriver. The integrated 1-meter USB cable connects systems immediately without the need for additional accessories or soldering. Clear terminal assignment and secure contact are ensured by 5-pin terminals with a pressure plate, labeled for ground, data lines, voltage, and shield, making it ideal for service, testing, and troubleshooting. Furthermore, the high signal quality is maintained through reliable insulation resistance and rated current capabilities, ensuring stable performance even under continuous load in demanding environments.

Suitable for

• Prototyping and testing electronic circuits
• Industrial automation and control systems
• Laboratory diagnostics and equipment commissioning
• DIY custom USB wiring and troubleshooting

When it may not be suitable

This product may not be suitable for high-speed data transfer exceeding USB 2.0 specifications or for supplying heavy power loads beyond the rated current of 0.7 A per pin. It is also not designed for permanent outdoor installation without additional weatherproof housing.

Key specifications

• Connector types: USB-C male to 5-pin terminal block female
• Cable length: 1 meter
• Connection technology: Screw terminal with pressure plate, 5.0 mm pitch
• Wire gauge support: 16–26 AWG
• Rated current: 0.7 A per pin
• Operating voltage: 5 V DC
• Operating temperature range: -20 °C to +105 °C
• Color: Black and green

How to use

To use the cable, strip the ends of your 16–26 AWG wires and insert them into the corresponding screw terminals on the 5-pin block, following the printed pin assignment for ground, data, voltage, and shielding. Secure the wires firmly using a flat-head screwdriver with a maximum width of 2.5 mm. Once the wiring is complete, plug the USB-C connector into the host device, controller, or measurement system to establish an immediate signal connection without any soldering required.

What to consider before purchase

• Verify that your application operates within the 0.7 A current limit per pin
• Check that your wire size falls within the 16–26 AWG range
• Confirm that your setup requires a USB 2.0 connection standard
• Ensure the 1-meter cable length is sufficient for your physical setup

Usage recommendations

Always verify terminal assignments and ensure power is disconnected before inserting or securing wires into the terminal block to prevent short circuits and protect connected equipment.
