Processor model:
The model number for the processor in a computer.
-
i3-1115G4
-
Internal memory type:
The type of internal memory such as RAM, GDDR5.
-
LPDDR4x
-
Wi-Fi standards:
The type of wireless local area network (LAN). It can be ad-hoc, where units in a network communicate peer-to-peer, or Infrastructure, where units communicate with each other via an access point A LAN interconnects computers in a small area e.g. home, school or office.
-
Wi-Fi 4 (802.11n), 802.11a, 802.11b, 802.11g, Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
-
Cabling technology:
Type of cable technology performance.
-
10/100/1000Base-T(X)
-
Processor manufacturer:
The manufacturer that produced the processor.
-
Intel
-
Ethernet LAN:
An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
-
Yes
-
Processor lithography:
The process which is performed by the processor e.g. CPU (Central Processing Unit).
-
10 nm
-
ECC:
ECC means Error Correction Code, and it is memory that is able to detect and correct some memory errors without user intervention.
-
No
-
Bluetooth:
Bluetooth is a low-power radio technology developed to replace the cables and wires currently used to link or connect electronic devices such as personal computers, printers, and a wide variety of handheld devices including mobile phones. Because it uses radio-wave connectivity, a Bluetooth-enabled device has a constant, established connection to whatever browser it uses. This saves the user the trouble of logging on to check for emails or news updates, for example.
-
Yes
-
Ethernet LAN (RJ-45) ports:
Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.
-
0
-
Compatible operating systems:
List of desktop operating systems tested as compatible with this product.
-
Windows 10, 64-bit*|Windows 10 IoT Enterprise*|Linux*
-
Memory clock speed:
The frequency at which the memory (e.g. RAM) runs.
-
4266 MHz
-
Wi-Fi:
Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.
-
Yes
-
HDMI ports quantity:
The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards.
-
1
-
Ethernet LAN data rates:
The different speed levels of the Ethernet LAN connection.
-
10, 100, 1000
-
Processor cores:
The number of central processing units ('cores') in a processor. Some processors have 1 core, others have 2 (e.g. Intel Core Duo) or more (e.g. the Intel Xeon E7-2850 has 10 cores).
-
2
-
DisplayPorts quantity:
Number of DisplayPorts. A DisplayPort is a digital display interface developed by the Video Electronics Standards Association (VESA). The interface is primarily used to connect a video source to a display device such as a computer monitor, though it can also be used to carry audio, USB, and other forms of data.
-
1
-
System bus rate:
A bus is a communication system that transfers data between components inside a computer, or between computers. The system bus rate is the speed at which data is transferred in this communication system.
-
4 GT/s
-
Processor threads:
-
4
-
Supported memory types:
Types of memory which can be used with the product.
-
LPDDR4x-SDRAM
-
Memory channels:
-
Dual-channel
-
Processor boost frequency:
The turbo boost is an automatic, managed accelleration of the processor when one of the cores is overloaded.
-
4.1 GHz
-
On-board graphics card:
Graphics hardware which is built into the motherboard or CPU, as opposed to a separate graphics adapter (video card). On-board graphics uses CPU and RAM for graphics processing.
-
No
-
Processor cache:
-
6 MB
-
Intel® AES New Instructions (Intel® AES-NI):
Added Security with Faster Data Encryption
The Intel® Advanced Encryption Standard New Instructions (Intel® AES-NI) enable fast and secure data encryption and decryption for better performance and less risk from timing and cache-based attacks than table-based software implementations. Intel AES-NI supports usages such as standard key lengths, standard modes of operation, and even some nonstandard or future variants.
-
Yes
-
Idle States:
-
Yes
-
Intel Trusted Execution Technology:
-
No
-
Number of displays supported:
The number of displays that can be used with this product.
-
4
-
Intel VT-x with Extended Page Tables (EPT):
-
Yes
-
Embedded options available:
-
No
-
Internal memory:
A computer's memory which is directly accessible to the CPU.
-
8 GB
-
Intel Stable Image Platform Program (SIPP):
-
No
-
Intel ME Firmware Version:
-
15
-
Intel Virtualization Technology for Directed I/O (VT-d):
Simplify Virtualization and Reduce Overheads
Intel® Virtualization Technology (Intel® VT) helps make virtualization practical by eliminating performance overheads, reducing complexity, and improving security with hardware assistance. Virtualization allows multiple workloads to share a common set of resources so that a variety of workloads can co-locate while maintaining full isolation from each other.
-
Yes
-
Intel Software Guard Extensions (Intel SGX):
-
No
-
Configurable TDP-down:
-
12 W
-
Processor cache type:
-
Smart Cache
-
Status:
-
Launched
-
Configurable TDP-down frequency:
-
1.7 GHz
-
Configurable TDP-up frequency:
-
3 GHz
-
Configurable TDP-up:
-
28 W
-
Intel Virtualization Technology (VT-x):
Simplify Virtualization and Reduce Overheads
Intel® Virtualization Technology (Intel® VT) helps make virtualization practical by eliminating performance overheads, reducing complexity, and improving security with hardware assistance. Virtualization allows multiple workloads to share a common set of resources so that a variety of workloads can co-locate while maintaining full isolation from each other.
-
Yes
-
Memory types supported by processor:
-
LPDDR4x-SDRAM
-
Number of displays supported (on-board graphics):
The feature may not be available on all computing systems. Functionality, performance, and other benefits of this feature may vary depending on system configuration.
-
4
-
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:
-
0
-
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity:
Number of USB 3.0 (3.1 Gen 1) ports with Type-C connector. USB 3.0 (3.1 Gen 1) is USB interface version which supports transfer rate up to 5 Gbit/s (SuperSpeed). USB Type-C connector has symmetrical design architecture and compatible with Thunderbolt 3 interface.
-
0
-
Harmonized System (HS) code:
-
84713000
-
Discrete graphics card:
-
No
-
Intel® Platform Trust Technology (Intel® PTT):
Intel® Platform Trust Technology (Intel® PTT) is a platform functionality for credential storage and key management used by Windows 8* and Windows® 10. Intel® PTT supports BitLocker* for hard drive encryption and supports all Microsoft requirements for firmware Trusted Platform Module (fTPM) 2.0.
-
Yes
-
Export Control Classification Number (ECCN):
-
5A992C
-
Commodity Classification Automated Tracking System (CCATS):
-
G157815L2
-
Intel® vPro™ Platform Eligibility:
-
No
-
Thunderbolt 4 ports quantity:
-
1
