Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
0.208 kg
-
Package weight:
Weight of the packaged product.
-
400 g
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
-20 - 65
-
Height:
The measurement of the product from head to foot or from base to top.
-
45 mm
-
Antenna type:
Type of antenna, also known an aerial, e.g. external, internal.
-
MIMO directional antenna
-
Width:
The measurement or extent of something from side to side.
-
130 mm
-
Depth:
The distance from the front to the back of something.
-
130 mm
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
White
-
Frequency band:
A small section of the spectrum of radio communication frequencies, in which channels are usually used or set aside for the same purpose e.g.for a channel on FM radio; for mobile networks to communicate with mobile phones.
-
2.4 - 5.9
-
Networking standards:
The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
-
IEEE 802.11ax, IEEE 802.11ac
-
Antenna gain level (max):
Antenna gain is the measurement of an antenna's ability to amplify the incoming microwave signals in a particular direction, compared with the sensitivity of an isotropic antenna in any direction, or a dipole antenna in the equatorial direction.
-
5 dBi
-
Cables included:
-
RG-178
-
Mounting:
What size the mounting head of the product is, to couple it with a camera.
-
Ceiling/wall
-
Impedance:
The effective resistance of an electric circuit or component to alternating current, arising from the combined effects of ohmic resistance and reactance.
-
50 Ω
-
Purpose:
What the product is used for.
-
Indoor
-
Antenna connector type:
The way in which the antenna is connected to the device e.g. coaxial.
-
RP-SMA
-
Polarization:
-
Dual polarization
-
Voltage Standing Wave Ratio (VSWR):
-
1,5:1 - 2,5:1
-
Country of origin:
Country where the device is made. Aka Country of manufacture (COM).
-
Taiwan
-
Housing material:
What the casing of the product is made of.
-
Plastic
-
Antenna gain (2.4 GHz):
-
3 dBi
-
Antenna gain (5 GHz):
-
5 dBi
-
Horizontal beam width (2.4 GHz):
-
360 °
-
Horizontal beam width (5 GHz):
-
220 °
-
Vertical beam width (5 GHz):
-
40 °
-
Vertical beam width (2.4 GHz):
-
55 °
-
Mounting kit:
-
Yes
-
Quantity per pack:
-
1 pc(s)
-
Harmonized System (HS) code:
-
85177100
-
Customs product code (TARIC):
-
85177000
