Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
0.01 kg
-
Certification:
-
MSA
-
Operating relative humidity (H-H):
-
10 - 80
-
Cabling technology:
Type of cable technology performance.
-
1000/10000
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-40 - 85
-
Package weight:
Weight of the packaged product.
-
32 g
-
Form factor:
The shape or design of the product.
-
SFP+
-
Plug and Play:
Indicates whether this product supports is "plug and play". Plug and play is hardware or software that, after being installed ("plugged in"), can immediately be used ("played with"), as opposed to hardware or software which requires configuration.
-
Yes
-
Interface type:
-
SFP+
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
0 - 70
-
Maximum data transfer rate:
The maximum speed with which data can be transmitted from one device to another.
-
10000 Mbit/s
-
Storage relative humidity (H-H):
-
10 - 85
-
Height:
The measurement of the product from head to foot or from base to top.
-
8.5 mm
-
Width:
The measurement or extent of something from side to side.
-
13.4 mm
-
Depth:
The distance from the front to the back of something.
-
56.5 mm
-
Compatible products:
Other products that can be used with this product.
-
Cisco 10GBASE-SR
-
Wavelength:
The distance over which a wave repeats itself. The wavelength determines the characteristics of the wave e.g. red light has a different wavelength to blue light.
-
850 nm
-
Hot-Plug support:
Device has hot-plug capability, which means that user can replace system components without shutting down the system.
-
Yes
-
Package depth:
The distance from the front to the back of the packaging.
-
67 mm
-
Package height:
The distance from the top to the bottom of the packaging.
-
24 mm
-
Package width:
The distance from one side of the packaging to the other.
-
106 mm
-
Easy to install:
-
Yes
-
Package type:
The type of product package e.g. box.
-
Window box
-
Fiber ports quantity:
The number of sockets (ports) for fibers (cables).
-
1
-
Auto MDI/MDI-X:
A Medium Dependent Interface (MDI) describes the interface (both physical and electrical) in a computer network from a physical layer implementation to the physical medium used to carry the transmission. Ethernet over twisted pair also defines a medium dependent interface crossover (MDIX) interface. Auto-MDIX ports on newer network interfaces detect if the connection would require a crossover, and automatically chooses the MDI or MDIX configuration to properly match the other end of the link.
-
Yes
-
Fiber optic connector:
This terminates the end of an optical fiber, and enables quicker connection and disconnection than splicing. The connectors mechanically couple and align the cores of fibers so light can pass. Better connectors lose very little light due to reflection or misalignment of the fibers. In all there have been about 100 types of optic fiber connectors produced.
-
LC
-
Brand compatibility:
What other brands this brand can be used with.
-
Cisco
-
Duplex system:
A duplex communication system is a point-to-point system composed of two connected parties or devices that can communicate with one another in both directions, simultaneously.
-
Full
-
Maximum transfer distance:
The greatest distance over which the data/signal can be transferred.
-
300 m
-
Fiber cable diameters supported (core/cladding):
-
50/125
-
SFP transceiver type:
-
Fiber optic
-
Digital Diagnostics Monitoring (DDM):
-
Yes
-
Multi-mode fiber (MMF) supported:
-
Yes
-
Single-mode fiber (SMF) supported:
-
No
-
SFP transceiver standard:
-
SR
