Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
0.04 kg
-
Certification:
-
MSA
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-40 - 85
-
Package weight:
Weight of the packaged product.
-
100 g
-
Form factor:
The shape or design of the product.
-
SFP
-
Plug and Play:
Indicates whether this product supports is "plug and play". Plug and play is hardware or software that, after being installed ("plugged in"), can immediately be used ("played with"), as opposed to hardware or software which requires configuration.
-
Yes
-
Interface type:
-
SFP
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
-45 - 75
-
Maximum data transfer rate:
The maximum speed with which data can be transmitted from one device to another.
-
1000 Mbit/s
-
Storage relative humidity (H-H):
-
10 - 85
-
Height:
The measurement of the product from head to foot or from base to top.
-
23 mm
-
Width:
The measurement or extent of something from side to side.
-
107 mm
-
Depth:
The distance from the front to the back of something.
-
65 mm
-
Compatible products:
Other products that can be used with this product.
-
Planet MGB-LX
-
Wavelength:
The distance over which a wave repeats itself. The wavelength determines the characteristics of the wave e.g. red light has a different wavelength to blue light.
-
1310 nm
-
Maximum operating temperature:
-
75 °C
-
Package depth:
The distance from the front to the back of the packaging.
-
65 mm
-
Package height:
The distance from the top to the bottom of the packaging.
-
23 mm
-
Package width:
The distance from one side of the packaging to the other.
-
107 mm
-
Easy to install:
-
Yes
-
Package type:
The type of product package e.g. box.
-
Window box
-
Fiber ports quantity:
The number of sockets (ports) for fibers (cables).
-
1
-
Fiber optic connector:
This terminates the end of an optical fiber, and enables quicker connection and disconnection than splicing. The connectors mechanically couple and align the cores of fibers so light can pass. Better connectors lose very little light due to reflection or misalignment of the fibers. In all there have been about 100 types of optic fiber connectors produced.
-
LC
-
Link budget:
-
15 dB
-
Brand compatibility:
What other brands this brand can be used with.
-
Planet
-
Duplex system:
A duplex communication system is a point-to-point system composed of two connected parties or devices that can communicate with one another in both directions, simultaneously.
-
Full
-
Maximum transfer distance:
The greatest distance over which the data/signal can be transferred.
-
20000 m
-
SFP transceiver type:
-
Fiber optic
-
Minimum operating temperature:
-
-45 °C
-
Digital Diagnostics Monitoring (DDM):
-
Yes
-
Multi-mode fiber (MMF) supported:
-
No
-
Single-mode fiber (SMF) supported:
-
Yes
-
Maximum transfer distance (Single-mode):
-
20000 m
-
SFP transceiver standard:
-
LX
