Electrical Complete Connector Lapp EPIC 21700638

The Lapp EPIC 21700638 electrical complete connector is a compact, crimp-type solution with flush mounting and nickel‑plated contacts. Designed for low-current signal and control circuits, the connector combines a narrow 13.9 mm width with a 38 mm height to fit installations with limited space while maintaining reliable electrical contact and mechanical stability.

Advantages

This connector offers durable nickel‑plated contacts that resist corrosion and provide stable conductivity over repeated mating cycles. The crimp termination method ensures secure conductor connection and consistent electrical performance. Its flush mounting design allows for a neat, space-saving installation in panels or enclosures. The 1 A current rating and compact form factor make it suitable where small, precise connections are required.

Suitable for

• Low-current signal wiring and control circuits
• Compact panel or enclosure installations with limited space
• Industrial equipment requiring corrosion-resistant contacts
• Applications where crimp termination is preferred for reliability

Key specifications

• Contact plating: nickel
• Termination type: crimp
• Mounting style: flush mounting
• Current rating: 1 A
• Width: 13.9 mm
• Height: 38 mm
• Intended use: electrical signal and control connections

How to use

Strip the conductor to the recommended length for the crimp contact, insert the conductor into the contact barrel and apply a suitable crimping tool to form a secure mechanical and electrical connection. Position the assembled contact into the connector housing until it clicks into place, then install the connector into the flush mounting cutout in the panel or enclosure. Verify correct mating with the counterpart and check continuity and insulation before energizing the circuit.

Usage recommendations

Use quality insulated conductors of appropriate gauge for the expected mechanical load; follow manufacturer guidance for crimp tooling and contact insertion. Avoid exceeding the 1 A current rating and perform routine inspections of contact condition in environments with corrosive agents or high humidity.
