Lapp EPIC Kit H-BE 6 SS TG M20 Complete Electrical Connector, Screw Termination

The Lapp EPIC Kit H-BE 6 SS TG M20 is a comprehensive industrial connector solution engineered for secure and reliable electrical connectivity. This complete set includes everything necessary for a robust installation, featuring a 6-pin configuration with a protective earth contact and a durable housing designed for demanding environments. By utilizing screw termination, the connector ensures a stable and vibration-resistant electrical path, while the integrated M20 cable gland provides effective strain relief and sealing for the connected cables.

Advantages

This connector kit stands out due to its high-quality construction and ease of assembly. The screw termination method allows for quick and reliable wire connections without the need for specialized crimping tools, making it highly versatile for field installations. The robust housing offers excellent protection against mechanical stress and environmental factors, ensuring long-term operational stability. Furthermore, the inclusion of all necessary components in a single kit simplifies the procurement process and guarantees compatibility between the insert and the housing.

Suitable for

• Industrial machinery and automation systems
• Control cabinet wiring
• Power distribution in harsh environments
• Electrical installations requiring secure, vibration-resistant connections

When it may not be suitable

This connector is not intended for high-speed data transmission applications or environments where extreme chemical exposure exceeds the material specifications of the housing. It is also not suitable for underwater submersion or applications requiring specialized IP ratings beyond the standard design specifications of this industrial connector.

Key specifications

• Number of contacts: 6 + PE
• Termination type: Screw termination
• Cable gland size: M20
• Housing type: Hood with cable entry
• Material: Industrial-grade metal/plastic composite

How to use

To use the Lapp EPIC Kit, first prepare your cables by stripping the insulation to the appropriate length. Insert the wires into the screw terminals on the connector insert and tighten the screws securely to ensure a firm electrical contact. Once the wiring is complete, slide the insert into the housing until it clicks into place. Finally, pass the cable through the M20 gland and tighten the gland nut to secure the cable and ensure the required level of environmental sealing.

What to consider before purchase

• Verify that the M20 cable gland size matches your cable diameter
• Ensure the 6-pin configuration meets your circuit requirements
• Check the environmental conditions of your installation site
• Confirm that screw termination is compatible with your wiring standards

Usage recommendations

Always ensure that the power supply is disconnected before performing any installation or maintenance on the connector. Periodically inspect the screw terminals for tightness, especially in high-vibration environments, to maintain optimal electrical performance.
