The Lapp EPIC Kit H-BE 6 BS AG is a comprehensive industrial connector solution engineered for demanding electrical environments. This complete set includes all necessary components to establish a secure and reliable connection, featuring a 6-pin plus protective earth configuration. Designed for durability and ease of installation, the kit utilizes a robust housing and high-quality contact inserts to ensure consistent performance in industrial machinery and control systems.
Advantages
This connector kit offers exceptional mechanical stability and electrical reliability, making it an ideal choice for professional industrial applications. The screw termination system allows for a secure and vibration-resistant connection without the need for specialized crimping tools, simplifying the assembly process. Its compact design and flush mounting capability ensure a clean, space-saving integration into control panels and equipment housings, while the high-quality materials provide excellent protection against environmental factors.
Suitable for
- Industrial automation and control systems
- Machinery and equipment manufacturing
- Power distribution panels
- Electrical installations requiring secure, disconnectable connections
This connector kit may not be suitable for applications involving extreme high-frequency signals or environments where high-speed data transmission is required, as it is primarily designed for power and control signal transmission. Additionally, it is not intended for use in underwater or highly corrosive chemical environments without additional protective measures.
Key specifications
- Current rating: 16 A
- Conductor cross-section: 0.5 to 2.5 mm²
- Number of contacts: 6 + PE
- Termination method: Screw termination
- Mounting type: Flush mounting
To use the Lapp EPIC Kit H-BE 6 BS AG, first prepare your cables by stripping the insulation to the appropriate length. Insert the conductors into the contact terminals and tighten the screws securely to ensure a firm electrical connection. Once the wiring is complete, assemble the contact insert into the housing and secure the unit to your mounting surface using the flush mounting configuration. Ensure that all seals and locking mechanisms are properly engaged to maintain the integrity of the connection.
What to consider before purchase
- Verify that the current and voltage requirements of your application match the 16 A rating.
- Ensure your cable cross-section falls within the 0.5 to 2.5 mm² range.
- Confirm that the flush mounting space is sufficient for the housing dimensions.
- Check the environmental conditions of the installation site to ensure compatibility with the connector housing.
For optimal performance and safety, always ensure that all screw terminals are tightened to the manufacturer's specified torque and that the cable is properly strain-relieved to prevent mechanical stress on the connection points.
