Lapp SKINTOP DIX-M 32290 Sealing Insert for M32 Cable Glands, 2 Holes, 9mm

The Lapp SKINTOP DIX-M 32290 is a professional-grade sealing insert engineered specifically for M32 cable glands. This component allows for the efficient and secure passage of two separate cables through a single entry point, ensuring that each cable is individually sealed. Designed to maintain the integrity of electrical enclosures, this insert provides a reliable barrier against environmental factors, supporting organized and safe cable management in various industrial settings.

Advantages

The primary benefit of this sealing insert is its ability to consolidate multiple cable entries, which saves space on the housing and simplifies the installation process. By utilizing a single gland for two cables, users can reduce the number of required components while maintaining a high standard of protection. The material is durable and specifically shaped to provide a tight fit, ensuring that the IP54 rating is achieved when installed correctly, effectively preventing the ingress of dust and water spray.

Suitable for

• Industrial control cabinets and electrical enclosures
• Automation systems requiring multi-cable routing
• Machinery and equipment installations
• Applications where space for cable glands is limited

When it may not be suitable

This sealing insert is not intended for use in environments requiring high-pressure washdowns or full submersion, as it is rated for IP54 protection. It is also not compatible with cable diameters that deviate significantly from the specified 9mm hole size, as this would compromise the sealing effectiveness.

Key specifications

• Compatible with M32 cable glands
• Number of holes: 2
• Hole diameter: 9mm
• Ingress protection rating: IP54
• Material: High-quality elastomer

How to use

To install the sealing insert, first ensure that the M32 cable gland is properly prepared. Remove the standard sealing ring from the gland and replace it with the SKINTOP DIX-M insert. Pass the two cables through the respective holes in the insert. Tighten the gland nut according to the manufacturer's torque specifications to compress the insert around the cables, creating a secure and sealed connection.

What to consider before purchase

• Verify that the cable gland size is M32
• Ensure the outer diameter of your cables matches the 9mm hole size
• Confirm that the IP54 protection level meets your environmental requirements
• Check the compatibility of the insert material with your specific operating environment

Usage recommendations

For optimal performance and to maintain the IP54 rating, ensure that the cables are inserted straight and are not under excessive tension. Avoid using cables with damaged outer jackets, as this will prevent a proper seal.
