LED SMD 0805 red 36–100 mcd 120° — surface-mount red LED 0805 package

Surface-mount red LED in an 0805 package providing a luminous intensity range of 36–100 mcd and a 120° viewing angle. This compact SMD red LED is intended for PCB assembly where space is limited and consistent color output and wide-angle visibility are required. The 0805 footprint is compatible with automated pick-and-place and reflow soldering processes, making it suitable for production of indicators, front-panel status lights and general backlighting tasks.

Advantages

The 0805 surface-mount design offers a very small footprint while maintaining stable red emission across the stated intensity range. A wide 120° viewing angle improves visibility from off-axis positions, reducing the need for additional optical components. The LED is compatible with standard SMT assembly methods and reflow profiles, enabling efficient mass production and repeatable placement. Consistent color output and moderate power requirements contribute to simple driver and circuit design.

Suitable for

• PCB indicators and status LEDs on control panels and instruments
• Backlighting for keypads, displays and symbol illumination
• Compact consumer electronics and wearable devices with constrained space
• Signals and indicators in industrial and automotive electronics where wide-angle visibility is needed

Key specifications

• Package type: 0805 SMD (surface-mount device)
• Color: red
• Luminous intensity: 36–100 mcd
• Viewing angle: 120°
• Mounting method: surface-mount (SMD) suitable for reflow soldering
• Typical use: indicator and backlight applications

How to use

Design the PCB pad layout to match the 0805 SMD footprint and follow manufacturer recommendations for solder land dimensions. During assembly, handle reels or trays according to SMT equipment requirements and program pick-and-place machines for the correct orientation. Use appropriate reflow soldering profiles for common SMD LEDs, ensuring peak temperatures and times are within standard limits for epoxy-encapsulated components. Drive the LED with a suitable current-limited source or series resistor to set the operating current consistent with the intended luminous intensity and to avoid exceeding the device’s rated forward current.

Usage recommendations

For reliable operation, specify a current that provides the required brightness while remaining below the device’s maximum ratings. Implement current-limiting and consider PWM dimming if variable brightness is needed. When designing optical layouts, account for the 120° viewing angle to optimize placement and minimize the number of LEDs required. Store and handle units in moisture-controlled conditions if recommended by your assembly process to prevent solderability issues.
