AV transmitter LevelOne HVE-9111T

Name: AV transmitter LevelOne HVE-9111T HVE-9111T
Brand: LEVELONE
SKU: 1101211
Price: 132.99 EUR
Availability: OutOfStock

JBL – powerful sound always with you

JBL speakers and headphones for pure and deep sound!

Short description

The LevelOne HDMI over Cat.5 Transmitter allows you to extend HDMI signals up to 300 meters using Cat5 cables. It supports a maximum resolution of 1920 x 1200 pixels, ensuring high-quality video output. With an AC input voltage of 5V and a maximum power consumption of 700 mA, it is efficient and reliable. Its compact dimensions (85 x 130 x 35 mm) make it easy to integrate into any setup, while the package dimensions ensure safe delivery.

Warranty: 2 Years

SKU: 1101211

Information regarding the items availability for purchase will be posted on this site

Item cost information will be published on this site

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The LevelOne HVE-9111T HDMI Transmitter is part of the HVE-91 series designed to extend Ultra/Full HD (4K/1080P) HDMI signals up to 300 metres over Ethernet cable. It includes a built-in 4K Ultra HD video scaler to adapt incoming signals and offers a local HDMI output and a link port for connection to a compatible receiver. The device provides long-range HDMI distribution without requiring optical fiber and supports EDID management and a screw-in power socket for secure power connection.

Advantages

The transmitter enables reliable long-distance transmission of 4K and 1080P content over standard Ethernet cabling, simplifying installations where fiber is not feasible. The integrated 4K scaler optimises the output for various input formats, while the local HDMI output allows a nearby display to be connected directly. EDID management ensures compatibility between source and display, and the screw-in power socket improves physical safety of the power connection.

Key specifications

Model: LevelOne HVE-9111T (HDMI Transmitter)
Supported resolutions: up to 4K2K (Ultra HD) and 1080P
Maximum transmission distance: up to 300 metres over Ethernet cable
Ports: 1 local HDMI output, 1 link port for receiver connection
Built-in 4K Ultra HD video scaler
EDID management supported
Power connector: screw-in power socket

How to use

Connect the HDMI source (player, PC, etc.) to the transmitter input, attach a local display to the transmitter's HDMI output if required, and run an Ethernet cable from the transmitter link port to a compatible HVE-91 receiver. Ensure the receiver is connected to the remote display and both devices are powered. Configure EDID settings if necessary to match source and display capabilities; the built-in scaler will adapt the output for optimal display performance.

Recommendations

For stable long-distance performance, use high-quality shielded Ethernet cable and ensure proper grounding. Verify EDID settings when connecting diverse source and display models, and secure the power connector to prevent accidental disconnection.

Specifications

Weight:: 0.365 kg
Product colour:: Black

All features

Ports & interfaces

HDMI in:: 1
Number of HDMI outputs:: 1
RJ-45 output ports:: 1

Technical details

Type:: AV transmitter
Maximum transfer distance:: 300 m
HDCP & EDID bypass:: Yes

Power

Input current:: 2
AC input voltage:: 5
Power consumption (transmitter) (max):: 700 mA

Weight & dimensions

Weight:: 0.365 kg
Height:: 35 mm
Width:: 85 mm
Depth:: 130 mm
Transmitter dimensions (WxDxH):: 130 x 97 x 35
Transmitter weight:: 358.9 g

Operational conditions

Operating relative humidity (H-H):: 10 - 90
Operating temperature (T-T):: 0 - 48

Packaging data

Package dimensions (WxDxH):: 170 x 295 x 120
Package weight:: 620 g
Package depth:: 295 mm
Package height:: 120 mm
Package width:: 170 mm

Packaging content

AC adapter included:: Yes
Quick start guide:: Yes

Logistics data

Country of origin:: Taiwan
Master (outer) case height:: 400 mm
Master (outer) case width:: 320 mm
Master (outer) case gross weight:: 1400 g
Master (outer) case length:: 630 mm
Products per master (outer) case:: 10 pc(s)

Features

LED indicators:: Power, Activity
Maximum resolution:: 1920 x 1200
Product colour:: Black
Supported video modes:: 1080p
Bandwidth:: 340 MHz
Maximum refresh rate:: 60 Hz

Network

Cable types supported:: Cat5

Hide Show all

Instructions

mmo_39492706_1510153808_9065_12566.pdf

levelone-HVE-9111T-1101211.pdf

Description

Instructions

mmo_39492706_1510153808_9065_12566.pdf

levelone-HVE-9111T-1101211.pdf
