Lightwin DC 12/8MM RED connector & cable seals Grey max 1.2 cm diameter

The Lightwin DC 12/8MM RED connector & cable seals in grey are designed to provide a water-resistant connection for cables up to 1.2 cm in diameter. Constructed for sealing and mechanical protection, the component offers resistance to water pressure up to 45 bar, ensuring secure contact and reduced risk of ingress in wet or pressurized environments. The compact design supports straightforward installation where a durable sealed cable entry is required.

Advantages

This sealing connector combines a compact footprint with reliable water-pressure resistance, enabling use in environments where moisture and pressure are present. The grey sealing body is compatible with the specified cable diameter and provides mechanical strain relief to protect the cable and contact points. The product’s construction supports repeatable installations and contributes to longer service life of wired connections by preventing water and particulate intrusion.

Suitable for

• Outdoor lighting and low-voltage power runs requiring sealed cable entries
• Electrical installations exposed to moisture or occasional pressurised water exposure
• Equipment enclosures where a compact sealed connection is needed
• Maintenance and repair tasks that require replacing or upgrading cable seals

Key specifications

• Maximum cable diameter: 1.2 cm
• Water pressure resistance: up to 45 bar
• Colour of seal: grey
• Intended cable size family: compatible with 12/8 mm cable configurations
• Function: cable sealing and mechanical strain relief for connectors

How to use

Verify the cable diameter does not exceed 1.2 cm and prepare the cable by stripping to the required length for the connector system in use. Insert the cable through the grey sealing element and position the seal so it compresses around the cable when the connector is assembled. Tighten or assemble the mating parts according to the connector manufacturer’s instruction to achieve the rated water-pressure resistance. Inspect the assembled connection to ensure the seal is evenly compressed and the cable is secured without kinks or undue stress.

Usage recommendations

For reliable performance, use the seal with cables within the specified diameter range and avoid over-tightening during assembly. Periodically inspect sealed connections exposed to harsh conditions for wear or deformation and replace seals if compression or integrity is compromised.
