Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-20 - 85
-
Plug and Play:
Indicates whether this product supports is "plug and play". Plug and play is hardware or software that, after being installed ("plugged in"), can immediately be used ("played with"), as opposed to hardware or software which requires configuration.
-
Yes
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
-10 - 80
-
Cable length:
How long the cable is.
-
10 m
-
Cable type:
Type of cable e.g. electicity cable, optical cable.
-
Round cable
-
Data transfer rate:
Rate at which data can be transferred. Usually expressed in units per second. May vary with network configurations.
-
18 Gbit/s
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Black
-
Magnetically shielded:
-
Yes
-
Package type:
The type of product package e.g. box.
-
Polybag
-
Supported graphics resolutions:
The graphic resolutions that can be displayed by the device. The graphic resolution describes the width and height dimensions of a display, such as a computer monitor, measured in pixels.
-
3840 x 2160
-
Supported video modes:
The video modes that can be displayed by the device.
-
2160p
-
Connector 1:
This is the first connector in the device.
-
HDMI Type A (Standard)
-
Connector 2:
This is the second connector in the device.
-
HDMI Type A (Standard)
-
Cable diameter:
The distance from one side of the cable to the other, with a straight line going through the middle of the cable.
-
5.5 mm
-
Connector contacts plating:
What the connector contacts are covered with (layer on top).
-
Gold
-
Maximum refresh rate:
-
60 Hz
-
3D:
The device can be used with 3D technology.
-
Yes
-
Dolby technologies:
-
Dolby TrueHD, DTS-HD Master Audio
-
Connector 1 form factor:
-
Straight
-
Connector 2 form factor:
-
Straight
-
AWG wire size:
-
28
-
Cable material:
The material e.g. copper, steel from which the cable is made.
-
Copper
-
Connector 1 gender:
The gender of the first connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the part bearing one or which fits into another being called male.
-
Male
-
Connector 2 gender:
The gender of the second connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the indented one or the one fitting around the other being called female.
-
Male
-
Cable jacket material:
-
Low smoke zero halogen (LSZH), Polyvinyl chloride (PVC)
-
Quantity per pack:
-
1 pc(s)
-
Shield material:
-
Aluminium
-
Bending radius (min):
-
60 mm
-
Supported digital audio channels (uncompressed):
-
32
-
Colour sampling:
-
4:4:4
-
Doesn't contain:
-
Halogen
-
Nominal attenuation:
-
300kHz~825MHz<5dB
825MHz~2.475GHz<5dB
2.475GHz~4.125GHz<12dB
4.125GHz~5.1GHz<20dB
-
Compliance certificates:
Indicates which regulatory, safety, and environmental standards the product complies with, as verified by recognized authorities or certification bodies.
-
REACH, RoHS
-
HDMI cable type:
-
High Speed HDMI cable
