MEAN WELL DCWN03B-05 electric converter

Name: MEAN WELL DCWN03B-05 electric converter DCWN03B-05
Brand: mean well
SKU: 4100851
Price: 22.99 EUR
Availability: InStock

JBL – powerful sound always with you

JBL speakers and headphones for pure and deep sound!

MEAN WELL DCWN03B-05 electric converter 3 W 18-36 V 300 mA

Keep track of price changes You keep track of price changes

Scan qr code below, or type in manually: {{secretKey}}

Forgot password? Registration

Offer for legal entity, cashless payment. Why is an item available only for a legal entity?
This is due to long delivery times and limited product warranties.

Short description

The MEAN WELL DCWN03B-05 is a compact electric converter with a power output of 3 W. It operates with a DC input voltage range of 18 to 36 V and provides an output current of 300 mA. This product is designed for efficient power conversion in various applications.

Available for order: 2 pcs.

Warranty: 2 Years

SKU: 4100851

Manufacturer: mean well

Learn more

Deliver the order:

{{ userCountryName }}

to the Customer Service Center at Kengaraga 2b, Riga

17.07.2026 {{selectedOffer.officeDeliveryString}}

free

All delivery methods Hide details

Customer service center

2b. Kengaraga str., Riga, Latvia, LV-1063

17.07.2026 {{selectedOffer.officeDeliveryString}}

free

Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!

22.07.2026 {{selectedOffer.courierDeliveryString}}

From 4.99 € (Weight: 0.01 kg)

Parcel couriers

Latvijas Pasts pakomāts / Unisend LV / DPD Paku skapis / Omniva LV / Venipak Pickup LV / Venipak Locker LV / Latvijas Pasts nodaļa

22.07.2026 {{selectedOffer.parcelStationDeliveryString}}

From 1.99 €

More about delivery methods

Payment Methods:

Bank transfer

More about payment methods

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The MEAN WELL DCWN03B-05 electric converter 3 W 18-36 V 300 mA is a compact DC-DC converter designed for applications that require a stable low-power current source. It accepts a wide DC input voltage range from 18 V to 36 V and provides a regulated output current of 300 mA with a maximum power of 3 W, enabling it to drive LEDs, sensors, and small control electronics where controlled current is needed. Its small form factor and straightforward electrical characteristics make it suitable for integration into lighting fixtures, industrial control modules, and battery-powered systems.

Advantages

This converter offers efficient conversion within its specified input range and maintains a constant output current of 300 mA, which simplifies the design of current-driven loads. The compact size reduces space requirements in enclosures and allows for easy mounting. Built with predictable electrical behaviour, it reduces the need for additional external current-regulation circuitry and eases thermal planning for low-power applications.

Suitable for

Driving LED arrays and single high-power LEDs requiring a 300 mA constant current
Powering sensors and instrumentation that need a stable low-power source
Integration into control modules, small industrial devices, and communication equipment
Battery-powered systems where input voltages fall within 18–36 V range

Key specifications

Input voltage range: 18–36 V DC
Output mode: constant current
Output current: 300 mA
Maximum output power: 3 W
Form factor: compact DC-DC converter suitable for panel or PCB mounting

How to use

Connect the converter to a DC supply within the 18–36 V range observing correct polarity. Connect the load to the output terminals, ensuring the load is rated for a constant 300 mA current and does not exceed the 3 W power limit. Verify connections and, if possible, measure output current and voltage under no-load and nominal-load conditions to confirm proper operation. Allow for adequate ventilation or mounting on a heat-dissipating surface for continuous operation within the rated power.

Usage recommendations

For reliable performance, use wiring sized to minimize voltage drop between the supply and the converter. Avoid operating at input voltages near the lower or upper limits if the supply is unstable; provide a regulated input when possible. When driving LEDs, include appropriate connectors and fusing on the input side and ensure the LED forward voltage and combined load do not exceed the converter’s 3 W capacity.

Specifications

Weight:: 0.0125 kg
Product colour:: Black

All features

Power:: 3 W
On/off switch:: No
Output current:: 300 mA
DC input voltage:: 18 - 36
USB connectivity:: No

Operational conditions

Operating temperature (T-T):: -40 - 90

Ports & interfaces

USB 2.0 ports quantity:: 0

Other features

Type:: DC/DC

Weight & dimensions

Weight:: 0.0125 kg
Height:: 10.2 mm
Width:: 20.3 mm
Depth:: 31.8 mm

Power

Output voltage:: -5 - 5

Design

Product colour:: Black

Performance

Certification:: RoHS, EN55032, CE, EAC

Logistics data

Country of origin:: China

Hide Show all
