header-product Power Supply Unit MEAN WELL MDR-10-5 10W Blue Metallic
14.91 €

Power Supply Unit MEAN WELL MDR-10-5 10W Blue Metallic

Power Supply Unit MEAN WELL MDR-10-5 Photo 1
Keep track of price changes You keep track of price changes
Watch the price drop

Leave your address - as soon as the price of the product goes down, you'll know about it right away

You keep track of price changes

Power Supply Unit MEAN WELL MDR-10-5 10W Blue Metallic

{{email}}
You keep track of price changes

Power Supply Unit MEAN WELL MDR-10-5 10W Blue Metallic

{{email}}
{{selectedOffer && selectedOffer.price | formatAmount}}

Short description

The MEAN WELL MDR-10-5 is a compact 10W power supply unit with a wide AC input voltage range of 85-264V and a passive cooling design. It features a mean time between failures (MTBF) of 584,000 hours, ensuring reliability. Approved by UL508 and TUV EN60950-1, this unit is suitable for various applications. Its dimensions are 22.5mm in width, 100mm in depth, and 90mm in height, making it an ideal choice for space-constrained environments.
Available for order: 7 pcs.
Warranty: 2 Years
SKU: 1621107
Manufacturer: mean well
free shipment

Cheapest delivery:

Unisend LV

Pick-up points

Unisend LV

Cost

1.79 €

Deliver

{{selectedOffer.parcelStationDeliveryString}}

Customer service center
2b. Kengaraga str., Riga, Latvia, LV-1063
Thursday {{selectedOffer.officeDeliveryString}}
free
Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!
28.07.2026 {{selectedOffer.courierDeliveryString}}
From 4.99 € (Weight: 0.16 kg)
Parcel couriers
Unisend LV / Venipak Pickup LV / Venipak Locker LV / Latvijas Pasts pakomāts / DPD Paku skapis / Omniva LV / Latvijas Pasts nodaļa
28.07.2026 {{selectedOffer.parcelStationDeliveryString}}
From 1.79 €
payment
Payment Methods:
Bank transfer, Bank cards on-line, Apple Pay, Google Pay
Together cheaper
{{product.price | formatAmount}}
{{product.title}}
{{productBundle.reference.specialPrice | formatAmount}}
{{productBundle.title}}
{{productBundlePreviousPrice | formatAmount}}
{{productBundleSpecialPrice | formatAmount}}

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The MEAN WELL MDR-10-5 is a compact 10W power supply unit with a wide AC input range of 85–264V and passive cooling. Designed for use in space-constrained installations, it has a metal blue housing and a measured MTBF of 584,000 hours. The unit is safety-approved to UL508 and TUV EN60950-1 standards and uses high-temperature electrolytic capacitors for extended life.

Advantages

The MDR-10-5 provides reliable operation across a full AC input range, survives 300VAC surges for short intervals, and endures high ambient temperatures up to 70°C. It has passed a 100% full-load burn-in test, meets vibration resistance up to 5G and employs 105°C long-life electrolytic capacitors to improve durability.

Suitable for

  • Industrial control panels and automation equipment
  • Embedded systems and compact enclosures
  • Low-power LED lighting and signage
  • Telecom or network devices requiring wide AC input

Key specifications

  • Model: MEAN WELL MDR-10-5 (MDR-10-5)
  • Output power: 10 W
  • Input voltage: 85–264 VAC (universal AC input)
  • Cooling: passive (fanless)
  • Approvals: UL508, TUV EN60950-1
  • MTBF: 584,000 hours
  • Operating temperature: up to 70°C
  • Surge withstand: 300 VAC for 5 seconds
  • Vibration: withstands 5G test
  • Capacitors: 105°C long-life electrolytic
  • Dimensions (W×D×H): 22.5 × 100 × 90 mm
  • Finish: blue metallic
  • EAN: 4021087020992

How to use

Install the MDR-10-5 in a well-ventilated, vibration-limited location inside the electrical enclosure. Connect the AC input within the specified 85–264 VAC range and wire the DC output to the load following the polarity markings and applicable wiring standards. Ensure the unit is mounted according to the manufacturer's spacing recommendations so passive cooling is not obstructed. Verify connections and test output voltage before placing the powered equipment into regular operation.

Usage recommendations

For reliable long-term operation, avoid mounting the unit directly on heat-generating components, keep airflow around the housing unobstructed, and apply proper surge protection where mains conditions are unstable. Periodically inspect terminal connections and replace the unit if electrolyte leakage or abnormal heating is observed.

All features
Weight:
0.17 kg
Mean time between failures (MTBF):
584000 h
Safety:
UL508, TUV EN60950-1 approved
Operating relative humidity (H-H):
20 - 90
Storage temperature (T-T):
-40 - 85
Operating temperature (T-T):
-20 - 70
Storage relative humidity (H-H):
10 - 95
Height:
90 mm
Width:
22.5 mm
Depth:
100 mm
Product colour:
Metallic, Blue
Input current:
0.33
Efficiency:
77 %
Hold time:
120 ms
Rise time:
30 ms
Cooling type:
Passive
Power protection features:
Short circuit, Overload, Over voltage
AC input frequency:
47 - 63
AC input voltage:
85 - 264
Total power:
10 W
