Keystone network outlet MetzConnect ISO/IEC Cat.6A 1‑port module 270M UP0

The MetzConnect ISO/IEC Cat.6A 1‑port keystone network outlet module provides a compact termination point for structured cabling systems where Cat.6A performance is required. Designed for installations in wall plates, patch panels or outlet boxes, this single‑port module supports high‑speed Ethernet links up to 10 Gigabit with performance aligned to the 270M UP0 specification. The module is intended to deliver consistent signal integrity for data, voice and video applications in commercial or residential network deployments.

Advantages

This keystone module offers Cat.6A-rated transmission characteristics in a standard 1‑port keystone format, enabling straightforward integration into common keystone frames and faceplates. Its design focuses on reliable electrical performance to meet ISO/IEC Cat.6A criteria and the 270M UP0 specification, helping to reduce interference and maintain link quality at higher frequencies. The compact form factor simplifies installation and replacement without requiring changes to existing structured cabling layouts.

Suitable for

• 10 Gigabit Ethernet connections in LAN infrastructures
• Structured cabling terminations in wall plates and patch panels
• Office, data centre or residential network outlets requiring Cat.6A performance
• Upgrades from Cat.5e/Cat.6 to Cat.6A where a single‑port modular outlet is needed

Key specifications

• Cable category: ISO/IEC Cat.6A performance class
• Port count: 1 port, keystone form factor
• Performance classification: aligned to 270M UP0 specification for Cat.6A
• Intended link speed: supports up to 10 Gigabit Ethernet
• Mounting: compatible with standard keystone faceplates and patch panels
• Application: data, voice and video transmission over twisted pair cabling

How to use

Terminate the copper twisted‑pair cable to the module following the colour code printed on the module or the installation documentation provided by the structured cabling standard in use. Insert the assembled keystone module into a compatible faceplate, outlet box insert or patch panel until it locks into place. Test the terminated link with a certified cable tester to verify Cat.6A performance and correct pair wiring before connecting active equipment. For patch panel use, ensure correct labelling to maintain network organisation.

Usage recommendations

To achieve the specified Cat.6A performance and the 270M UP0 characteristics, use certified Cat.6A twisted‑pair cable and maintain appropriate cable management practices: avoid sharp bends, minimise untwisted pair length at termination, and keep data cabling separate from strong electrical sources. Verify link performance with an appropriate certification tester after installation.
