Digital signage flat panel NEC MultiSync M861

Name: Digital signage flat panel NEC 60005067
Brand: NEC
SKU: 9706553
Price: 3117.49 EUR
Availability: OutOfStock

EcoFlow – energy without limits

Powerful EcoFlow stations for energy anywhere!

Digital signage flat panel NEC MultiSync M861 86" LCD 4K Ultra HD

Digital signage flat panel NEC MultiSync M861 Photo 1

Digital signage flat panel NEC MultiSync M861 Photo 2

Digital signage flat panel NEC MultiSync M861 Photo 3

Digital signage flat panel NEC MultiSync M861 Photo 4

Digital signage flat panel NEC MultiSync M861 Photo 5

Digital signage flat panel NEC MultiSync M861 Photo 6

Digital signage flat panel NEC MultiSync M861 Photo 7

Digital signage flat panel NEC MultiSync M861 Photo 8

Digital signage flat panel NEC MultiSync M861 Photo 9

Digital signage flat panel NEC MultiSync M861 Photo 10

Short description

The NEC MultiSync M861 is a 86" digital signage flat panel featuring LCD technology and a stunning 4K Ultra HD resolution of 3840 x 2160 pixels. With a brightness of 500 cd/m², it ensures clear visibility in various lighting conditions. Designed for 24/7 operation, this monitor is ideal for continuous use in commercial environments. Its sleek black design complements any setting, making it a perfect choice for digital signage applications.

Warranty: 2 Years

SKU: 9706553

Information regarding the items availability for purchase will be posted on this site

Item cost information will be published on this site

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The NEC MultiSync M861 is an 86" digital signage flat panel with LCD IPS technology and 4K Ultra HD resolution (3840 x 2160). With 500 cd/m² brightness, an 8000:1 contrast ratio, and 24/7 operation capability, the display is designed for continuous commercial use. Its slim black housing, high-haze panel to reduce reflections and optional computing modules (NEC MediaPlayer or Intel® Smart Display Module) enable professional content delivery and flexible installation for advertising, infotainment and meeting room applications.

Advantages

The M861 offers reliable 24/7 performance, high resolution for detailed visuals and a high-haze panel that reduces reflections in bright environments. IPS LCD technology provides wide viewing angles and consistent colour reproduction, while optional integrated media players (NEC MediaPlayer or Intel® SDM) deliver scalable computing power for real-time media playback. VESA mounting and built-in speakers simplify installation and use in diverse signage scenarios.

Suitable for

Retail advertising and in-store promotions
Transport hubs and public information displays
Corporate lobbies and meeting room presentation screens
Hospitality and infotainment installations

Key specifications

Display diagonal: 86"
Resolution: 3840 x 2160 (4K Ultra HD)
Panel type: IPS LCD
Brightness: 500 cd/m²
Contrast ratio (typical): 8000:1
Response time: 8 ms
VESA mounting: Yes
Built-in speakers: Yes
Operation: 24/7
Colour: Black
Weight: 47 kg
Energy class (SDR): G — 193 kWh/1000 h

How to use

Mount the display using a compatible VESA bracket or professional mounting solution, connect power and the chosen content source, and configure the NEC MediaPlayer or Intel® Smart Display Module if using an integrated player. Adjust brightness and image settings as required for the installation environment. For continuous operation, ensure adequate ventilation and follow NEC’s installation guidelines.

Usage recommendations

For best results in bright locations, use the high-haze panel and set brightness to match ambient light; use the Intel® SDM for demanding content or multiple simultaneous streams, and schedule regular maintenance checks during continuous 24/7 operation.

Specifications

Display diagonal: Size of the display for this product, measured diagonally, usually in inches.: 86 "
Display resolution: The number of distinct pixels in each dimension that can be displayed. It is usually quoted as width × height, with the units in pixels: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels. The higher the number of pixels, the sharper the image.: 3840 x 2160
HD type: Type of supported High Definition (e.g. Full HD, 4K Ultra HD).: 4K Ultra HD
Panel type:: IPS
Display technology: The technology used in the display e.g. plasma, LED.: LCD
Power consumption (typical): Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.: 320 W
Energy efficiency class (SDR): Energy efficiency class is a standard classification that is used all over Europe and which is understandable at first sight. Products can be efficiently compared according to classes, starting from A (the most energy efficient class), and ending with G (the most energy-intensive class). The classification of energy efficiency is based on annual energy consumption which is being calculated on the basis of several different parameters.: G
VESA mounting:: Yes
Ethernet LAN: An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.: Yes
DisplayPorts quantity: Number of DisplayPorts. A DisplayPort is a digital display interface developed by the Video Electronics Standards Association (VESA). The interface is primarily used to connect a video source to a display device such as a computer monitor, though it can also be used to carry audio, USB, and other forms of data.: 2
HDMI ports quantity: The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards.: 3
Product design: The creation of a plan or convention for the construction of an object or a system.: Digital signage flat panel
Purpose: What the product is used for.: Universal
Built-in speaker(s): The device contains speaker(s) to produce sound.: Yes
Product colour: The colour e.g. red, blue, green, black, white.: Black

All features

Operational conditions

Storage relative humidity (H-H):: 10 - 80
Storage temperature (T-T): The minimum and maximum temperatures at which the product can be safely stored.: -20 - 60
Operating relative humidity (H-H):: 20 - 80
Operating temperature (T-T): The minimum and maximum temperatures at which the product can be safely operated.: 0 - 40

Packaging content

Cables included:: HDMI, Power
Batteries included:: Yes
Remote control included: Component of an electronics device, most commonly a television set, DVD player and home theater systems originally used for operating the device wirelessly from a short line-of-sight distance.: Yes

Packaging data

Package weight: Weight of the packaged product.: 65100 g
Package height: The distance from the top to the bottom of the packaging.: 1225 mm
Package depth: The distance from the front to the back of the packaging.: 225 mm
Package width: The distance from one side of the packaging to the other.: 2090 mm

Weight & dimensions

Weight: Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.: 47 kg
Height: The measurement of the product from head to foot or from base to top.: 1099.1 mm
Depth: The distance from the front to the back of something.: 83.2 mm
Width: The measurement or extent of something from side to side.: 1927.6 mm

Power

AC input frequency:: 50 - 60
AC input voltage: The voltage of the AC electricity that is inputted into the product.: 100 - 240
Energy consumption (SDR) per 1000 hours: Power consumption in switched-on state expressed in W.: 193 kWh
Power consumption (typical): Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.: 320 W
Energy efficiency class (SDR): Energy efficiency class is a standard classification that is used all over Europe and which is understandable at first sight. Products can be efficiently compared according to classes, starting from A (the most energy efficient class), and ending with G (the most energy-intensive class). The classification of energy efficiency is based on annual energy consumption which is being calculated on the basis of several different parameters.: G

Ergonomics

VESA mounting:: Yes

Network

Ethernet LAN data rates: The different speed levels of the Ethernet LAN connection.: 100
Ethernet LAN: An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.: Yes

Ports & interfaces

DisplayPorts out:: 1
USB port: The device features a socket into which a USB cable can be plugged.: Yes
USB ports quantity:: 3
DisplayPorts in:: 2
DisplayPorts quantity: Number of DisplayPorts. A DisplayPort is a digital display interface developed by the Video Electronics Standards Association (VESA). The interface is primarily used to connect a video source to a display device such as a computer monitor, though it can also be used to carry audio, USB, and other forms of data.: 2
HDMI output ports quantity:: 1
HDMI input ports quantity:: 2
USB version: Universal Serial Bus (USB) is an industry standard developed in the mid-1990s that defines the interface used for connection, communication and power supply between computers and electronic devices. Every new version - for example 1.1, 2.0, 3.0 - is much faster than the previous one.: 2.0
HDMI ports quantity: The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards.: 3

Design

Bezel width (top):: 14.3 mm
Bezel width (side):: 14.3 mm
Bezel width (bottom):: 14.8 mm
Panel mounting interface: The product can be used wih VESA mounting interfaces.: 600 x 400
Orientation:: Horizontal/Vertical
Product colour: The colour e.g. red, blue, green, black, white.: Black
Product design: The creation of a plan or convention for the construction of an object or a system.: Digital signage flat panel

Performance

HDCP: High-bandwidth Digital Content Protection (HDCP) is a form of digital copy protection to prevent copying of digital audio and video content as it travels across connections.: Yes
Purpose: What the product is used for.: Universal
Operating hours (hours/days):: 24/7

Display

Horizontal scan range:: 15 - 135
Vertical scan range:: 23 - 76
Display diagonal (metric): This is the size of the display screen, measured diagonally.: 217.4 cm
Display number of colours:: 1.073 billion colours
Contrast ratio (typical): The difference in light intensity between the brightest white and the darkest black.: 8000:1
Response time: The response time is the time difference between the moment that a source (for example a video card) sends a signal and that equipment (for example a monitor) receives or display the signal. (Used abbreviations: R/F = Rise and Fall.): 8 ms
Native aspect ratio: The aspect ratio is the ratio of the width of an image to its height. The native aspect ratio is the one which the projector/display is particularly designed for. Images shown in native aspect ratio will utilize the entire resolution of the display and achieve maximum brightness. Images shown in other than native aspect ratio will always have less resolution and less brightness than images shown in native aspect ratio.: 16:9
Haze rate:: 28 %
Display brightness: Brightness is the amount of radiating light emitted from the screen. The brightness rating is measured in candellas per square meter, commonly known as 'nits'.: 500 cd/m²
Panel type:: IPS
HD type: Type of supported High Definition (e.g. Full HD, 4K Ultra HD).: 4K Ultra HD
LED backlighting type: Backlighting is the illumination of a screen e.g. LCD (liquid crystal display). There are several types of backlighting with LEDs, e.g. full array, edge lit.: Direct-LED
LED backlight: A backlight is a form of illumination used in liquid crystal displays (LCDs). One type of backlight is made by LEDs, which can be either white or RGB (red green blue). White LEDs are used most often in notebooks and desktop screens, and in virtually all mobile LCD screens. RGB LEDs for backlighting are found in high-end color proofing displays such as HP DreamColor LP2480zx monitor or selected HP EliteBook notebooks, as well as newer consumer grade displays such as Dell's Studio series laptops which have an optional RGB LED display.: Yes
Display technology: The technology used in the display e.g. plasma, LED.: LCD
Display diagonal: Size of the display for this product, measured diagonally, usually in inches.: 86 "
Display resolution: The number of distinct pixels in each dimension that can be displayed. It is usually quoted as width × height, with the units in pixels: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels. The higher the number of pixels, the sharper the image.: 3840 x 2160

Audio

RMS rated power: RMS (Root mean square) is a measure of the continuous power required by a device, in particular audio amplifiers and loudspeakers.: 10 W
Number of built-in speakers:: 2
Built-in speaker(s): The device contains speaker(s) to produce sound.: Yes

Hide Show all

Instructions

mmo_101713184_1739542304_1606_1192417.pdf

nec-60005067-9706553.pdf

nec-60005067-9706553(1).pdf

nec-60005067-9706553(2).pdf

Description

Instructions

mmo_101713184_1739542304_1606_1192417.pdf

nec-60005067-9706553.pdf

nec-60005067-9706553(1).pdf

nec-60005067-9706553(2).pdf

Machine translation.

Show details Hide details

{{highlightedFeature.featureTitle}}:

{{getProductFeatureValueById(product, highlightedFeature.featureId)}}

Customer reviews

Show all reviews

Customer questions

FAQ

What payment options are available?

AiO.lv offers several payment methods: Bank transfer, Leasing for legal entities. All transactions are 100% secure and encrypted.

Can this product be purchased for a company (with VAT)?

Yes. AiO.lv works with legal entities in Latvia and across Europe. The product price already includes VAT. For certain product categories, as well as for companies from other EU countries with a valid VAT number, a 0% VAT rate may apply. We issue the invoice immediately after the order is placed, support electronic BIS invoices, and automatically generate all necessary accounting documents. You can complete the purchase for a company online — simply select the company profile and choose bank transfer as the payment method during checkout.

What is the warranty period?

All NEC products come with an official 2 Years warranty. It covers all manufacturing defects and malfunctions that may occur during use. The warranty is valid at all authorized NEC service centers and through AiO.lv

Can the product be returned after purchase?

Yes, you can return the product within 14 days of purchase if you bought it as a consumer (not a legal entity). Returns are possible without giving any reason — the main condition is that the product retains its original appearance and full set of accessories. We will make the process as simple and convenient as possible: just contact our customer support team, and we will help you arrange the return.

Where should I contact for warranty service?

For warranty-related questions you can contact the AiO.lv (SIA VSPRO) customer support team. We will assist with consultation, warranty claim processing, and coordination with certified service centers.

How can I tell if this product suits my needs?

When making a choice, we recommend paying attention to the key features: display diagonal, display resolution, hd type, panel type, display technology, power consumption (typical), energy efficiency class (sdr), vesa mounting, ethernet lan, displayports quantity, hdmi ports quantity, product design, purpose, built-in speaker(s), product colour, compatibility with your devices or usage conditions, material quality, functionality, and warranty terms. These characteristics will help you determine how well the model meets your needs.

Where can I download the instructions for Digital signage flat panel NEC MultiSync M861?

You can download the instructions in PDF format from the “Instructions” section on the product description page. The file contains complete information about installation, setup, and usage.
