Instrument microphone Nedis MPWD25BK — wired XLR-3, 80–13,000 Hz, 72 dB sensitivity, 5 m cable, black

The Nedis MPWD25BK wired instrument microphone is a unidirectional dynamic microphone engineered to capture instrument sound accurately in live and studio environments. It features an XLR-3 connector for reliable balanced audio transmission, a frequency response of 80–13,000 Hz to reproduce a wide range of instrument timbres, and a sensitivity of 72 dB. The microphone combines an aluminium and ABS housing with a durable metal body and a 5 m integrated cable, providing a compact 345 g form factor and a black finish suited for stage and recording setups.

Advantages

The MPWD25BK offers focused pickup with its unidirectional polar pattern, reducing unwanted background noise and feedback in live situations. Its wired XLR-3 connection ensures stable signal integrity and compatibility with professional mixers and interfaces. The aluminium and ABS construction with a metal grille delivers mechanical durability while keeping the unit lightweight enough for stands and clamps. The 80–13,000 Hz frequency range and 72 dB sensitivity make it suitable for many acoustic and amplified instruments.

Suitable for

• Close-miking amplifiers and guitar cabinets
• Acoustic instruments such as guitars, brass and woodwinds
• Drum kit close miking (toms, snare) and percussion
• Live stage performances and rehearsal rooms
• Home and project studio instrument recording

Key specifications

• Type: Unidirectional dynamic instrument microphone
• Connectivity: Wired with XLR-3 connector
• Frequency response: 80–13,000 Hz
• Sensitivity: 72 dB
• Cable length: 5 m (integrated)
• Housing materials: Aluminium and ABS with metal components
• Colour: Black
• Weight: Approximately 345 g
• Power: DC operation

How to use

Connect the MPWD25BK to a mixer, audio interface or preamp using the XLR-3 connector, ensuring a secure, balanced connection. Position the microphone close to the sound source, aiming the unidirectional capsule toward the instrument to maximise direct sound pickup and minimise room noise. Adjust gain on the input device to achieve a clean signal without clipping; dynamic microphones typically require more preamp gain than condenser types. Mount the microphone on a suitable stand or clip and route the 5 m cable to avoid trip hazards and interference.

Izmantošanas ieteikumi

For best results, place the microphone 1–10 cm from the instrument or amplifier speaker cone for close-miking applications, and experiment with angle and distance to find the desired balance between attack and body. Avoid placing the microphone directly in front of loudspeaker ports without an attenuating pad or high-pass filtering if available. Use a shock mount or isolation clip if excessive mechanical noise from stands or stages is present.
