Cable connector NETRACK Krone IDC Cat.6 STP 106-82 — Krone IDC punch-down module

NETRACK Krone IDC Cat.6 STP 106-82 is a Krone-style punch-down module engineered for Category 6 shielded twisted-pair cabling. The connector provides insulation displacement contact (IDC) terminations without soldering, enabling consistent electrical contact and preserving the shield continuity required for STP (shielded twisted pair) installations. It is intended for use in patch panels, distribution frames and network cabinets where Cat6 performance and shielding are required.

Advantages

This Krone IDC module delivers reliable, repeatable terminations for Cat6 STP cabling while minimising installation time thanks to the IDC principle. The design maintains shield continuity and reduces the need for post-termination adjustments. Mechanical stability and stable contact pressure are achieved without soldering or crimping, which helps reduce installation errors and ensures consistent network performance for Ethernet applications up to Cat6 specifications.

Suitable for

• Structured cabling deployments in data centres and server rooms
• Patch panels and distribution frames requiring shielded Cat6 terminations
• Network cabinets and wall-mounted enclosures with STP cabling
• Installations that need quick, tool-assisted punch-down terminations

Key specifications

• Cable category: Category 6 (Cat6) compatible with shielded twisted pair (STP)
• Termination type: Insulation displacement contact (IDC) punch-down
• Contact style: Krone-type punch-down footprint for modular installation
• Use case: Designed for patch panels, distribution frames and network cabinets
• Electrical: Maintains shield continuity for STP cabling

How to use

Prepare the shielded Cat6 cable by removing the outer jacket and exposing the shield and twisted pairs according to the cable manufacturer’s recommendations. Arrange pairs following the colour code, position conductors into the Krone IDC slots, and use a compatible punch-down tool to terminate each conductor until the IDC cuts through insulation and forms the contact. Ensure the cable shield is properly connected to the module’s grounding path or chassis to maintain overall shield continuity.

Usage recommendations

Use a dedicated Krone-style punch-down tool for consistent terminations and verify continuity of all pairs and shield with appropriate testing equipment after installation. Avoid excessive mechanical stress on the terminated cable, and follow local grounding and bonding practices to ensure the shield provides effective interference protection.
