Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
0.032 kg
-
Package weight:
Weight of the packaged product.
-
50 g
-
Plug and Play:
Indicates whether this product supports is "plug and play". Plug and play is hardware or software that, after being installed ("plugged in"), can immediately be used ("played with"), as opposed to hardware or software which requires configuration.
-
Yes
-
Cable length:
How long the cable is.
-
0.7 m
-
Cable type:
Type of cable e.g. electicity cable, optical cable.
-
Round cable
-
Input voltage:
The voltage (V) which is required to power the product.
-
20
-
Output voltage:
-
20
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Black
-
Maximum data transfer rate:
-
10 Gbit/s
-
Package depth:
The distance from the front to the back of the packaging.
-
100 mm
-
Package height:
The distance from the top to the bottom of the packaging.
-
20 mm
-
Package width:
The distance from one side of the packaging to the other.
-
100 mm
-
Master (outer) case height:
-
110 mm
-
Master (outer) case width:
-
210 mm
-
Package type:
The type of product package e.g. box.
-
Box
-
Connector 1:
This is the first connector in the device.
-
USB C
-
Connector 2:
This is the second connector in the device.
-
USB C
-
Cable diameter:
The distance from one side of the cable to the other, with a straight line going through the middle of the cable.
-
5 mm
-
Connector contacts plating:
What the connector contacts are covered with (layer on top).
-
Gold
-
USB version:
Universal Serial Bus (USB) is an industry standard developed in the mid-1990s that defines the interface used for connection, communication and power supply between computers and electronic devices. Every new version - for example 1.1, 2.0, 3.0 - is much faster than the previous one.
-
USB 3.2 Gen 2 (3.1 Gen 2)
-
Connector 1 form factor:
-
Straight
-
Connector 2 form factor:
-
Straight
-
AWG wire size:
-
32
-
DisplayPort version:
-
1.4
-
Connector 1 gender:
The gender of the first connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the part bearing one or which fits into another being called male.
-
Male
-
Connector 2 gender:
The gender of the second connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the indented one or the one fitting around the other being called female.
-
Male
-
Master (outer) case gross weight:
-
1660 g
-
Cable jacket material:
-
Nylon
-
Quantity per pack:
-
1 pc(s)
-
Master (outer) case length:
-
355 mm
-
Products per master (outer) case:
-
30 pc(s)
-
Output current (max):
-
5 A
-
Input current (max):
-
5 A
-
USB Type-C DisplayPort Alternate Mode:
-
Yes
-
USB Power Delivery (USB PD):
-
Yes
-
USB Power Delivery revision:
-
3.1
-
USB Power Delivery up to:
-
100 W
-
Compliance certificates:
Indicates which regulatory, safety, and environmental standards the product complies with, as verified by recognized authorities or certification bodies.
-
REACH, RoHS
