Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
1.486 kg
-
Certification:
-
FCC Part 15 Class A, CE
-
Rack mounting:
The type of mounting that can position devices in a shelving system (rack).
-
Yes
-
Full duplex:
A full-duplex system allows communication in both directions, and unlike half-duplex, allows this to happen simultaneously.
-
Yes
-
MAC address table:
The MAC address is the 'Media Access Control Address'. It is a unique address given to a network interface controller (NIC) in a device. A MAC address table shows the addresses in a table format.
-
8000 entries
-
Operating relative humidity (H-H):
-
5 - 95
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-10 - 70
-
Form factor:
The shape or design of the product.
-
1U
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
-10 - 60
-
Storage relative humidity (H-H):
-
5 - 95
-
Power source:
What is providing power for the product e.g. mains electricity.
-
AC/DC
-
Height:
The measurement of the product from head to foot or from base to top.
-
44 mm
-
LED indicators:
-
Yes
-
Width:
The measurement or extent of something from side to side.
-
330 mm
-
Depth:
The distance from the front to the back of something.
-
153 mm
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Blue
-
Switching capacity:
The data transfer capacity of the switch per second.
-
68 Gbit/s
-
Networking standards:
The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
-
IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3bz, IEEE 802.3x, IEEE 802.3z
-
Switch layer:
A network switch is a computer networking device that links networking segments. A switch has different layers, such as layer 2 (a network bridge, operating at the data link layer, interconnecting a small number of devices) and layer 4 (can act as a firewall, amongst other things).
-
L3
-
Quality of Service (QoS) support:
-
Yes
-
Link aggregation:
-
Yes
-
Jumbo frames support:
-
Yes
-
Redundant power supply (RPS) support:
Additional power supply which can run a computer if the main power supply fails.
-
Yes
-
Multicast support:
-
Yes
-
Web-based management:
Using a website/web application to manage something.
-
Yes
-
Store-and-forward:
-
Yes
-
System event log:
-
Yes
-
Rate limiting:
-
Yes
-
Switch type:
What switch device has, managed or unmanaged.
-
Managed
-
Auto MDI/MDI-X:
A Medium Dependent Interface (MDI) describes the interface (both physical and electrical) in a computer network from a physical layer implementation to the physical medium used to carry the transmission. Ethernet over twisted pair also defines a medium dependent interface crossover (MDIX) interface. Auto-MDIX ports on newer network interfaces detect if the connection would require a crossover, and automatically chooses the MDI or MDIX configuration to properly match the other end of the link.
-
Yes
-
Spanning tree protocol:
-
Yes
-
VLAN support:
A Virtual Local Area Network (VLAN) consists of a group of computers and switches that can be physically distributed over different networks and buildings, but form one LAN on a logical level.
-
Yes
-
AC input frequency:
-
50 - 60
-
AC input voltage:
The voltage of the AC electricity that is inputted into the product.
-
100 - 240
-
DC input voltage:
-
24
-
Installed SFP+ modules quantity:
An SFP ("small form-factor pluggable transceiver") is a transmitter/receiver which interfaces a network device motherboard (e.g. in a switch, router) to a fibre optic or copper network cable. The enhanced small form-factor pluggable (SFP+) is an enhanced version of the SFP that supports data rates up to 10 Gbit/s. The "SFP+ ports quantity" is the number of ports for SFP+ connections in a device.
-
2
-
Installed SFP modules quantity:
An SFP ("small form-factor pluggable transceiver") is a transmitter/receiver which interfaces a network device motherboard (e.g. in a switch, router) to a fibre optic or copper network cable. The "SFP ports quantity" is the number of ports for SFP connections in a device.
-
6
-
Basic switching RJ-45 Ethernet ports quantity:
The number of basic switching RJ-45 Ethernet ports (sockets).
-
2
-
Throughput:
-
50.59 Mpps
-
Auto-negotiation:
-
Yes
-
Traffic classification:
-
Yes
-
Traffic shaping:
-
Yes
-
ARP inspection:
-
Yes
-
Jumbo frames:
-
10000
-
MAC address auto-learning supported:
-
Yes
-
MAC address auto-aging supported:
-
Yes
-
Cloud-managed:
-
Yes
