Power Supply Unit PLANET PWR-75-24

Name: Power Supply Unit PLANET PWR-75-24 PWR-75-24
Brand: PLANET
SKU: 125149
Price: 38.49 EUR
Availability: InStock

EcoFlow – energy without limits

Powerful EcoFlow stations for energy anywhere!

Power Supply Unit PLANET PWR-75-24 75 W Blue Grey

Keep track of price changes You keep track of price changes

Scan qr code below, or type in manually: {{secretKey}}

Forgot password? Registration

Offer for legal entity, cashless payment. Why is an item available only for a legal entity?
This is due to long delivery times and limited product warranties.

Short description

The PLANET PWR-75-24 is a reliable 75 W power supply unit with a wide AC input voltage range of 100 - 240 V and frequency of 50 - 60 Hz. It features a passive cooling design, ensuring quiet operation. With safety certifications including UL508 and TUV EN60950-1, this unit is perfect for various applications. Its compact dimensions (32 mm width, 102 mm depth, 125 mm height) make it easy to integrate into different setups.

Available at price 38.49 €: 30 pcs.

Total available for order: 70 pcs.

Warranty: 2 Years

SKU: 125149

Learn more

Deliver the order:

{{ userCountryName }}

to the Customer Service Center at Kengaraga 2b, Riga

01.07.2026 {{selectedOffer.officeDeliveryString}}

free

All delivery methods Hide details

Customer service center

2b. Kengaraga str., Riga, Latvia, LV-1063

01.07.2026 {{selectedOffer.officeDeliveryString}}

free

Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!

06.07.2026 {{selectedOffer.courierDeliveryString}}

From 4.99 € (Weight: 0.46 kg)

Parcel couriers

Latvijas Pasts pakomāts / Unisend / DPD Paku skapis / Omniva / Venipak Pickup / Venipak Locker / Latvijas Pasts nodaļa

06.07.2026 {{selectedOffer.parcelStationDeliveryString}}

From 1.99 €

More about delivery methods

Payment Methods:

Cash payment, Bank transfer, Bank cards on-line, Apple Pay, Google Pay

Available for private customers at price 43.49 €: 1 pcs.

More about payment methods

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The PLANET PWR-75-24 is a compact 75 W DIN-rail power supply designed for industrial Ethernet devices and other industrial equipment. It accepts a wide AC input range of 100–240 V (50–60 Hz) and can also accept DC input, providing a regulated 24 V DC output. The unit features passive (free air convection) cooling, a slim housing (32 mm width, 102 mm depth, 125 mm height) and is mountable on TS-35/7.5 or 15 DIN rails, making it suitable for installations with limited space.

Advantages

The PWR-75-24 offers stable performance in harsh environments through protections against short circuit, overload, over-voltage and over-temperature. Its passive cooling ensures quiet operation while allowing an operating temperature range from -20 °C up to 70 °C (maximum). Safety certifications such as UL508 and TUV EN60950-1 and a compact, lightweight design (approx. 0.5 kg) simplify integration into industrial racks and cabinets.

Suitable for

Industrial Ethernet switches and networking equipment
DIN-rail mounted industrial control systems
Automation modules and sensors requiring 24 V DC
Environments with limited installation space

Key specifications

Output power: 75 W
Output voltage: 24 V DC
Input voltage: 100–240 V AC (50–60 Hz); accepts DC input
Cooling: Passive (free air convection)
Protections: Short circuit, overload, over-voltage, over-temperature
Operating temperature: -20 °C to 70 °C (maximum)
Mounting: DIN rail TS-35/7.5 or 15
Dimensions (W x D x H): 32 x 102 x 125 mm
Weight: ~0.5 kg
Certifications: UL508, TUV EN60950-1

How to use

Mount the unit securely on a TS-35/7.5 or 15 DIN rail and connect the AC (100–240 V) supply or a compatible DC source to the input terminals following local wiring regulations. Connect the 24 V DC output to the load, observing correct polarity. Ensure adequate ventilation around the unit for passive cooling and avoid placing it near heat sources. Verify fuse or circuit protection on the input side as required by your installation standards.

Usage recommendations

For reliable long-term operation, keep the ambient temperature within the specified range, allow at least 20 mm clearance above and below the unit for airflow, and confirm compatibility of the load with a 24 V DC 75 W power source. Use appropriate circuit protection and follow applicable safety standards during installation.

Specifications

Weight:: 0.5 kg
Product colour:: Grey, Blue

All features

Cooling type:: Passive
Total power:: 75 W

Logistics data

Harmonized System (HS) code:: 84733020

Operational conditions

Operating relative humidity (H-H):: 20 - 95
Storage temperature (T-T):: -40 - 85
Operating temperature (T-T):: -20 - 70
Storage relative humidity (H-H):: 10 - 95

Design

Safety:: Ul508, TUV EN60950-1
Product colour:: Grey, Blue

Power

Input current:: 1.45
Power protection features:: Short circuit, Overload, Overheating, Over voltage
AC input frequency:: 50 - 60
AC input voltage:: 100 - 240

Weight & dimensions

Weight:: 0.5 kg
Height:: 125 mm
Width:: 32 mm
Depth:: 102 mm

Hide Show all

Instructions

planet-PWR-75-24-125149.pdf

Description

Instructions

planet-PWR-75-24-125149.pdf

Machine translation. Load original

{{highlightedFeature.featureTitle}}:

{{getProductFeatureValueById(product, highlightedFeature.featureId)}}

Warehouse	Stock	Delivery to the store	Store Price
EU3	1	01.07.2026 Best delivery	43.49 €
WH354	30	08.07.2026	44.99 €

Available only for legal entities
Warehouse	Stock	Delivery to the store	Store Price
EU6	30	01.07.2026 Best delivery	38.49 € Best price
EU4	9	15.07.2026	43.49 €

43.49 €

Stock: 1

Delivery Date: 01.07.2026 Best delivery

Warehouse: EU3

44.99 €

Stock: 30

Delivery Date: 08.07.2026

Warehouse: WH354

Available only for legal entities

38.49 €

Stock: 30

Delivery Date: 01.07.2026 Best delivery

Warehouse: EU6

43.49 €

Stock: 9

Delivery Date: 15.07.2026

Warehouse: EU4

Customer reviews

Show all reviews

Customer questions

FAQ

How much does the Power Supply Unit PLANET PWR-75-24 cost, and is it available for purchase?

The price is 38.49 € (valid at the time of publication and already includes all taxes). The item is available for order — 70 pcs. are in stock, and you can place your purchase right now with delivery across Latvia and Europe or choose pickup at the Riga collection point. We offer favorable purchase terms, including the option to split the payment into convenient monthly installments. Availability and price are updated in real time, so we recommend placing your order in advance.

If I order this product today, when will I receive my order?

If you place your order today, delivery will be as fast and convenient as possible. You will be able to pick up your order on 01.07.2026 at the Riga pickup point or choose delivery across Latvia and Europe. We carefully inspect every purchase and pack it securely for safe transportation.

What payment options are available?

AiO.lv offers several payment methods: Cash payment, Bank transfer, Bank cards on-line, Apple Pay, Google Pay. All transactions are 100% secure and encrypted.

Can this product be purchased for a company (with VAT)?

Yes. AiO.lv works with legal entities in Latvia and across Europe. The product price already includes VAT. For certain product categories, as well as for companies from other EU countries with a valid VAT number, a 0% VAT rate may apply. We issue the invoice immediately after the order is placed, support electronic BIS invoices, and automatically generate all necessary accounting documents. You can complete the purchase for a company online — simply select the company profile and choose bank transfer as the payment method during checkout.

What is the warranty period?

All PLANET products come with an official 2 Years warranty. It covers all manufacturing defects and malfunctions that may occur during use. The warranty is valid at all authorized PLANET service centers and through AiO.lv

Can the product be returned after purchase?

Yes, you can return the product within 14 days of purchase if you bought it as a consumer (not a legal entity). Returns are possible without giving any reason — the main condition is that the product retains its original appearance and full set of accessories. We will make the process as simple and convenient as possible: just contact our customer support team, and we will help you arrange the return.

Where should I contact for warranty service?

For warranty-related questions you can contact the AiO.lv (SIA VSPRO) customer support team. We will assist with consultation, warranty claim processing, and coordination with certified service centers.

How can I tell if this product suits my needs?

When making a choice, we recommend paying attention to the key features: weight, product colour, compatibility with your devices or usage conditions, material quality, functionality, and warranty terms. These characteristics will help you determine how well the model meets your needs.

Where can I download the instructions for Power Supply Unit PLANET PWR-75-24?

You can download the instructions in PDF format from the “Instructions” section on the product description page. The file contains complete information about installation, setup, and usage.
