Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
0.038 kg
-
Interface type:
-
SFP
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
0 - 70
-
Maximum data transfer rate:
The maximum speed with which data can be transmitted from one device to another.
-
1250 Mbit/s
-
Ethernet LAN:
An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
-
No
-
Height:
The measurement of the product from head to foot or from base to top.
-
115 mm
-
Width:
The measurement or extent of something from side to side.
-
45 mm
-
Depth:
The distance from the front to the back of something.
-
20 mm
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Stainless steel
-
Wavelength:
The distance over which a wave repeats itself. The wavelength determines the characteristics of the wave e.g. red light has a different wavelength to blue light.
-
1490 nm
-
Fiber optic connector:
This terminates the end of an optical fiber, and enables quicker connection and disconnection than splicing. The connectors mechanically couple and align the cores of fibers so light can pass. Better connectors lose very little light due to reflection or misalignment of the fibers. In all there have been about 100 types of optic fiber connectors produced.
-
LC
-
RX sensitivity:
-
-23 dB
-
Maximum transfer distance:
The greatest distance over which the data/signal can be transferred.
-
20000 m
-
SFP transceiver type:
-
Fiber optic
-
Tx power (max):
-
-3 dBmW
-
Tx power (min):
-
-9 dBmW
-
Quantity per pack:
-
1 pc(s)
-
Wavelength-division multiplexing (WDM):
-
Yes
-
Single-mode fiber (SMF) supported:
-
Yes
-
SFP transceiver standard:
-
BX
