Relpol PI6W-1P-115VAC/DC Relay Socket for RM699BV, 6.2mm Width

The Relpol PI6W-1P-115VAC/DC is a high-quality interface relay socket specifically engineered for use with RM699BV miniature relays. Featuring a remarkably slim 6.2mm width, this component is designed to maximize space efficiency within crowded electrical cabinets and industrial automation panels. It provides a stable and secure mounting platform, ensuring reliable electrical connectivity for control systems operating at 115V AC/DC.

Advantages

The primary benefit of this relay socket is its ultra-compact design, which allows for high-density mounting on standard DIN rails, significantly reducing the footprint required for control logic. The modular construction facilitates rapid installation and simplifies maintenance procedures, as individual relays can be replaced without disturbing the surrounding wiring. Furthermore, the robust build quality ensures long-term operational reliability in demanding industrial environments, protecting the integrity of the signal path.

Suitable for

• Industrial automation and control systems
• PLC output and input interface modules
• Electrical cabinet space optimization
• Signal switching in control panels

This relay socket may not be suitable for applications requiring high-current switching beyond the capacity of the RM699BV relay or for environments exposed to extreme vibration or corrosive elements that exceed the IP rating of the enclosure. It is also not intended for use with relays that do not conform to the specific physical and electrical interface requirements of the PI6W-1P series.

Key specifications

• Operating voltage: 115V AC/DC
• Width: 6.2mm
• Compatibility: RM699BV relays
• Mounting type: DIN rail

To use the Relpol PI6W-1P-115VAC/DC, snap the socket onto a standard 35mm DIN rail until it clicks into place. Insert the compatible RM699BV relay into the socket, ensuring the pins are correctly aligned with the terminals. Connect the control and load wires to the designated screw terminals, ensuring all connections are tightened to the manufacturer's specified torque to prevent loose contacts.

What to consider before purchase

• Verify the voltage requirements of your control circuit match the 115V AC/DC rating
• Ensure the relay model being used is compatible with the PI6W-1P series
• Check available space on the DIN rail to accommodate the 6.2mm width

Always ensure the power supply is disconnected before installing or replacing the relay to prevent electrical shock or damage to the control equipment.
