Ricoh guide pull-out lock D1381568 — replacement guide component for compatible Ricoh printers

Replacement guide component Ricoh D1381568 (guide: pull out: lock) is a mechanical spare part intended for compatible Ricoh office printers and multifunction devices. It functions as a pull-out locking guide that secures paper paths or removable modules, helping restore correct media feeding, alignment and module fixation after wear or accidental damage. The part is suitable for technicians and service personnel carrying out routine maintenance, repairs or refurbishment of Ricoh equipment.

Advantages

This pull-out lock guide provides precise mechanical positioning with a simple locking action that reduces play in removable trays and modules. Because it is a direct replacement component designed for Ricoh devices, it maintains original fit and function while helping to prevent paper misfeeds and alignment issues. Its durable construction supports repeated insertion and locking cycles typical in office environments.

Suitable for

• Repair and maintenance of compatible Ricoh office printers and MFPs
• Replacing worn or damaged guides that affect paper feeding or removable module fixation
• Service workshops restoring proper alignment and mechanical operation
• Refurbishment projects where original-style guide components are required

Key specifications

• Function: mechanical guide with pull-out locking mechanism
• Application: secures paper paths or removable modules in office printers
• Material: durable engineering plastic and metal reinforcement where required
• Operation: manual pull-out and lock engagement for positive fixation
• Compatibility: designed for use in compatible Ricoh models and assemblies

How to use

Turn off and unplug the printer before beginning any repair. Access the area where the guide is fitted by opening the indicated cover or removing the affected module according to the device service manual. Remove the damaged guide by releasing any retaining clips or screws, then install the replacement guide by aligning it with the guide rails and engaging the pull-out lock until it clicks into place. Reassemble any removed components, power on the unit and perform a test feed to confirm correct alignment and function.

Usage recommendations

Use genuine or manufacturer-compatible replacement parts and follow the device service instructions. If paper feed or alignment issues persist after installation, inspect adjacent rollers, sensors and trays for wear or obstruction and consult a qualified technician when needed.
