Wall/floor mounting bracket Rittal CP 6206.800 for CP 60 enclosures — cast aluminium and plastic, grey/white

The Rittal CP 6206.800 is a support arm mounting kit designed for secure attachment of support arm systems to vertical or horizontal surfaces. It combines cast aluminium and plastic construction with a grey-and-white finish, providing a durable mounting solution for industrial enclosures and components.

Advantages

The cast aluminium body offers strength and resistance to deformation while plastic elements reduce weight and protect contact surfaces. The grey and white colour scheme is neutral for industrial settings. The design enables reliable fixation of support arms to walls or floors, simplifying installation and ensuring stable mounting for downstream equipment.

Suitable for

• Mounting support arms for electrical enclosures
• Fixing articulation or support systems to vertical walls
• Floor or horizontal surface mounting where a stable base is required
• Industrial or technical rooms with metal or solid structural surfaces

When it may not be suitable

This mounting kit is intended for mechanical support of arm systems on solid surfaces; it is not a complete support arm or enclosure and will not serve as a substitute for structural reinforcement in weak or hollow substrates. For installations on thin sheet metal, drywall, or other low-strength materials, additional reinforcement or appropriate anchors are required.

Key specifications

• Materials: cast aluminium and plastic
• Colour: grey and white finish
• Application: wall and floor mounting for support arm systems
• Designed for stable mechanical fixation to vertical and horizontal surfaces

How to use

Position the mounting bracket on the chosen vertical or horizontal surface, mark drilling points, and secure the bracket using appropriate fasteners for the substrate. Attach the support arm system to the bracket according to the arm manufacturer’s instructions, ensuring all bolts and connectors are tightened to the specified torque. Verify alignment and load capacity before use.

What to consider before purchase

• Compatibility of the bracket with the support arm system dimensions and attachment points
• Type and strength of the mounting surface (concrete, steel, wood, drywall)
• Required fasteners and anchors for the substrate
• Environmental conditions that may affect material selection (indoor, outdoor, corrosive)

Usage recommendations

Use appropriate corrosion-resistant fasteners for the surface and verify load ratings of both the mounting bracket and the support arm system. If in doubt about substrate strength, consult a structural technician to determine suitable reinforcement or anchoring methods.
