Fuse holder Rittal SV 9345.005, 3-pole, 30 A, 600 V, light grey

Rittal SV 9345.005 is a 3-pole fuse holder for Class CC fuses, rated for 30 A and up to 600 V. Finished in light grey, this fuse holder is designed for secure installation in electrical panels and control cabinets, providing a reliable mechanical and electrical connection for protecting three-phase or multi-pole circuits in industrial and commercial environments.

Advantages

This Rittal fuse holder offers compact, space-efficient mounting for three poles in a single unit and is compatible with Class CC fuse cartridges designed for 30 A applications. The robust housing ensures stable electrical contact and insulation, while the neutral light-grey finish supports clear component identification inside control cabinets. Installation and replacement of fuses are straightforward, reducing downtime during maintenance.

Suitable for

• Protection of three-phase circuits in industrial control panels
• Commercial electrical installations requiring Class CC fuses
• Retrofit and repair tasks in switchgear and distribution boards
• Applications where a compact, three-pole fuse holder is needed

When it may not be suitable

This fuse holder is intended for Class CC fuse cartridges and is not suitable for fuse types with different dimensions or for single-pole protection where a one-pole holder would be sufficient. It must be used within its rated current (30 A) and voltage (600 V); applications exceeding these ratings require a different device.

Key specifications

• Number of poles: 3
• Rated current: 30 A
• Rated voltage: 600 V
• Fuse class compatibility: Class CC
• Colour/finish: light grey
• Mounting: panel/control cabinet mounting

How to use

Mount the Rittal SV 9345.005 fuse holder into the panel or control cabinet according to enclosure drilling or mounting rail requirements, ensuring secure mechanical fixation. Insert the appropriate Class CC fuse cartridges for each pole and connect incoming and outgoing conductors to the designated terminals, observing correct torque values and tightening sequence as specified by installation standards. Verify that the holder and fuses are rated for the intended circuit before energising and perform insulation and continuity checks after installation.

What to consider before purchase

• Confirm compatibility with Class CC fuse cartridges and the required 30 A rating
• Ensure the 600 V rated voltage matches the system voltage
• Check available panel space and mounting method for a 3-pole holder
• Verify terminal type and conductor cross-section compatibility

Usage recommendations

Use only manufacturer-recommended Class CC fuses sized for the circuit protection requirements. During installation and maintenance, de-energise the circuit and follow local electrical codes and safety procedures. Periodically inspect the holder and fuse contacts for signs of overheating or corrosion and replace components as needed to maintain reliable protection.
