UPS ROLINE DesignSecure 1200

Name: UPS ROLINE DesignSecure 1200 19.40.1212
Brand: ROLINE
SKU: 1626056
Price: 278.49 EUR
Availability: InStock

Dreame – powerful cleaning with ease

Dreame vacuums for fast and efficient cleaning!

Keep track of price changes You keep track of price changes

Scan qr code below, or type in manually: {{secretKey}}

Forgot password? Registration

Offer for legal entity, cashless payment. Why is an item available only for a legal entity?
This is due to long delivery times and limited product warranties.

Short description

The ROLINE DesignSecure 1200 is a Line-Interactive UPS with a power capacity of 1.2 kVA and 720 W output. It features 6 AC outlets (C13 coupler) and provides a typical backup time of 3 minutes at full load and 6 minutes at half load. With a compact tower form factor and passive cooling, it is designed for efficient power management. Dimensions: 105 mm (W) x 334 mm (D) x 168 mm (H).

Available for order: 21 pcs.

Warranty: 2 Years

SKU: 1626056

Learn more

Cheapest delivery:

Unisend LV

Pick-up points

Unisend LV

Cost

1.79 €

Deliver

All delivery methods Hide details

Customer service center

2b. Kengaraga str., Riga, Latvia, LV-1063

24.08.2026 {{selectedOffer.officeDeliveryString}}

free

Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!

27.08.2026 {{selectedOffer.courierDeliveryString}}

From 13.04 € (Weight: 16.50 kg)

Parcel couriers

Unisend LV / Venipak Locker LV / Latvijas Pasts pakomāts / DPD Paku skapis / Omniva LV

27.08.2026 {{selectedOffer.parcelStationDeliveryString}}

From 1.79 €

More about delivery methods

Payment Methods:

Bank transfer

More about payment methods

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The ROLINE DesignSecure 1200 is a compact Line-Interactive UPS designed for workstations and PCs. It delivers up to 1.2 kVA (720 W) output power, provides six C13 AC outlets and includes automatic voltage regulation (AVR), integrated surge protection and EMI/RFI noise filtering in a small tower housing with passive cooling.

Advantages

This UPS combines AVR and integrated overvoltage protection to stabilise voltage fluctuations and protect connected equipment. A digital status display and USB port allow advanced power management and monitoring, while telephone/modem protection and an EMI/RFI filter reduce interference. The compact, futuristic design and moderate weight make it suitable for desktop environments where space is limited.

Suitable for

Desktop PCs and workstations
Small office equipment and peripherals
Network devices with telephone/modem connections
Environments requiring voltage regulation and surge protection

Key specifications

Model: ROLINE DesignSecure 1200 (MPN: 19.40.1212)
Output power: 720 W
Output power capacity: 1.2 kVA
AC outlets: 6 × C13
USB: 1 × USB 2.0 port (for power management software)
Features: Line-Interactive topology, AVR, integrated surge protection, EMI/RFI filter
Connections: Telephone/Modem protection
Dimensions (H×W×D): 168 × 105 × 334 mm
Weight: 6.3 kg
Typical backup time: up to 3 minutes at full load; approximately 6 minutes at half load (typical)
Colour: Black, Silver

How to use

Place the UPS on a flat, stable surface with adequate ventilation. Connect critical devices to the C13 AC outlets and attach telephone/modem lines if required. Install the included power management software via the USB 2.0 port to enable advanced monitoring and controlled shutdowns. The unit operates automatically to regulate voltage and supply battery power during mains failures; monitor the digital status display for real-time information.

Usage recommendations

Ensure regular testing and periodic battery replacement according to the manufacturer’s guidelines. Avoid blocking ventilation openings, and do not expose the UPS to moisture or extreme temperatures. For uninterrupted operation of multiple high-draw devices, verify total load does not exceed 720 W output capacity.

Specifications

Form factor: The shape or design of the product.: Tower
Input frequency: The frequency (Hz) which is required to power the product.: 50
Input operation voltage (min): The minumum voltage needed by the device during operation.: 230 V
Output power: The power that the device can produce.: 720 W
Output power capacity: The maximum power that the device can produce.: 1.2 kVA
UPS topology: The two main UPS topologies are Double-Conversion True Online and Standby / Eco. Many quality-based considerations are involved when choosing the the optimal UPS for the job, like how they are coping with voltage disturbances.: Line-Interactive
Product colour: The colour e.g. red, blue, green, black, white.: Silver, Black

All features

Other features

Nominal output voltage: The voltage which the manufacturer states that the device can produce.: 230
Nominal input voltage: The voltage which the manufacturer recommends that the device needs to operate normally.: 230
Dimensions (WxDxH): Dimensions of the product (Width x Depth x Height).: 168 x 105 x 334
Number of phases:: 1

Weight & dimensions

Weight: Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.: 6.3 kg
Height: The measurement of the product from head to foot or from base to top.: 168 mm
Depth: The distance from the front to the back of something.: 334 mm
Width: The measurement or extent of something from side to side.: 105 mm

Operational conditions

Operating temperature (T-T): The minimum and maximum temperatures at which the product can be safely operated.: 0 - 40

Design

LED indicators:: Yes
Display type: Type of display (screen) e.g. LCD.: LED
Cooling type: The method used to cool the device or to cool the air around the device.: Passive
Product colour: The colour e.g. red, blue, green, black, white.: Silver, Black
Form factor: The shape or design of the product.: Tower

Battery

Hot-swap battery:: No
Typical backup time at half load: The amount of time that a backup energy source (e.g. UPS - Uninterruptible Power Source) can power the device for, when the backup energy source is half-loaded (50% of capacity).: 6 min
Typical backup time at full load: The amount of time that a backup energy source (e.g. UPS - Uninterruptible Power Source) can power the device for, when the backup energy source is fully loaded (100% of capacity).: 3 min

Ports & interfaces

Modem (RJ-11) ports:: 2
USB 2.0 ports quantity: Number of USB 2.0 ports (connecting interfaces) in the device. USB 2.0 was released in April 2000 (now called "Hi-Speed"), adding higher maximum signaling rate of 480 Mbit/s (effective throughput up to 35 MB/s or 280 Mbit/s), USB 2.0 ports are usually black.: 1
AC outlets quantity: The number of sockets in the device where AC electrical power can be connected.: 6 AC outlet(s)
Power plug: A power plug is a 2 or 3 pinned device that is placed into an electrical socket in order to make an electrical connection.: C14 coupler
AC outlet types: The type of outlet for AC electricity.: C13 coupler

Features

Power protection features: Features that protect the device against power problems e.g. overload.: Over voltage
Surge protection:: Yes
Number of output phases:: 1
Automatic Voltage Regulation (AVR):: Yes
Output operation voltage (min): The minumum voltage produced by the device during operation.: 230 V
Input frequency: The frequency (Hz) which is required to power the product.: 50
Input operation voltage (min): The minumum voltage needed by the device during operation.: 230 V
Output power: The power that the device can produce.: 720 W
Output power capacity: The maximum power that the device can produce.: 1.2 kVA
UPS topology: The two main UPS topologies are Double-Conversion True Online and Standby / Eco. Many quality-based considerations are involved when choosing the the optimal UPS for the job, like how they are coping with voltage disturbances.: Line-Interactive
