19-inch freestanding network cabinet ROLINE Pro 26U, 800x800 mm, glass door, grey, 600 kg

ROLINE 19-inch freestanding network cabinet Pro 26U with 800x800 mm footprint and glass front door is designed for secure indoor installation of 19" rack equipment up to 26U and a maximum load of 600 kg. The enclosure features a robust steel construction with sheet thickness up to 1.5 mm, electrostatic powder coating in grey (RAL 7035), removable side panels and doors, adjustable depth rails and multiple cable inlet options for flexible network cabling in offices, server rooms and telecommunications closets.

Advantages

The cabinet provides a stable load capacity of up to 600 kg while maintaining a compact 800x800 mm footprint, making it suitable where floor space is limited. Removable front and rear doors plus modular side panels allow easy access for installation and maintenance. Built-in brush inlets in roof and base areas, a slide-on inlet with foam rubber seal and vertical cable ducts facilitate tidy cable routing. The stepped, removable top cover with ventilation slots supports improved airflow and the easy mounting of fan modules. Two pairs of galvanised, reversible and depth-adjustable 19" profile rails ensure flexible mounting of equipment.

Suitable for

• Small to medium office server rooms and network closets
• Telecom and network cabinets for patch panels, switches and routers
• Indoor IT infrastructure installations requiring a glass front for visual access
• Environments where modular access and cable management are needed

Key specifications

• Form factor: 19-inch freestanding network cabinet, 26U usable rack height
• Footprint: 800 x 800 mm (width x depth)
• Maximum static load: 600 kg
• Construction: steel sheet, up to 1.5 mm thickness
• Finish: electrostatic powder coating, grey (RAL 7035)
• Front door: glass door (transparent viewing panel)
• Access: removable front and rear doors, removable side panels, changeable door hinge
• Cable management: brush inlets in roof and base, slide-on base inlet with foam seal, brush strips on rear door, vertical cable ducts with cover
• Cooling provisions: stepped removable top cover with ventilation slots and fan-module mounting option
• Internal rails: two pairs of galvanised 19" profile rails, reversible and depth-adjustable, connected to additional depth struts
• Protection class: IP20 (suitable for indoor use)

How to use

Place the cabinet on a level indoor surface and adjust the feet to achieve a stable position. Remove the front, rear or side panels as required for mounting equipment. Fit servers, switches, patch panels and other 19" devices onto the galvanised profile rails, adjusting the rail depth to match equipment depth. Route cables through brush inlets, the slide-on base inlet or vertical cable ducts to keep cabling organised and to maintain access to rear connections. Use the stepped top cover and ventilation slots to install fan modules if additional active cooling is required.

Usage recommendations

For safe operation, distribute the load evenly across the cabinet and secure heavy units at lower positions to maintain stability. Keep cable entries sealed with the provided brush strips and foam seal to reduce dust ingress. Ensure adequate ventilation and, if necessary, add fan modules in the top cover to support heat dissipation. The cabinet is intended for indoor use in dry environments and complies with IP20 protection.
