ROLINE 19-inch network cabinet Pro 32U 800x800 mm freestanding rack, glass door, grey, 600 kg, IP20

ROLINE 19-inch network cabinet Pro 32U 800x800 mm is a freestanding rack designed for mounting 19" server, network and telecom equipment in offices and small data rooms. The cabinet has a 32U usable height and an 800×800 mm footprint (W×D). Constructed from robust steel with sheet thickness up to 1.5 mm and finished in grey (RAL 7035) powder coating, it includes a glass front door, removable side panels and rear door, adjustable internal 19" rails and adjustable feet. The cabinet supports a maximum static load of 600 kg and has an IP20 protection rating; total weight is 90.2 kg.

Advantages

The Pro series design offers flexible cable management with brush inlets in roof and base areas, a slide-on inlet in the base chassis with foam rubber seal, and brush strips around the rear door for tidy cabling and reduced dust ingress. Vertical cable ducts with covers are mounted alongside the profile rails to keep cabling organised. Two pairs of galvanised 19" profile rails are depth-adjustable and reversible, and the stepped removable top cover with ventilation slots facilitates airflow and fan module installation. Modular removable panels and changeable door hinges provide straightforward access for installation and maintenance.

Suitable for

• Mounting 19" servers and rack-mount network switches
• Small data rooms and server closets in offices
• Telecom and patching equipment with organised cable routing
• Environments requiring secure front access (glass front door) and moderate environmental protection (IP20)

Key specifications

• Rack height: 32U usable height
• External footprint (W×D): 800 × 800 mm
• Construction material: steel, sheet thickness up to 1.5 mm
• Front door: glass
• Side and rear panels: removable for access
• Internal rails: two pairs of galvanised 19" profile rails, reversible and depth-adjustable
• Cable management: brush inlets (roof and base), slide-on base inlet with foam seal, brush strips at rear door, vertical cable ducts with covers
• Ventilation: stepped removable top cover with ventilation slots for fan module installation
• Load capacity: maximum static load 600 kg
• Protection class: IP20
• Total weight: 90.2 kg
• Finish: electrostatic powder coating, grey (RAL 7035)

How to use

Position the freestanding cabinet on a stable, level surface and adjust the feet to achieve correct levelling. Remove front, rear or side panels as required to install equipment; mount devices to the 19" profile rails using appropriate rack screws and cage nuts, adjusting rail depth to suit equipment depth. Use the brush inlets, slide-on base inlet and vertical cable ducts to route and secure power and network cabling while maintaining separation of power and data where needed. Install fans in the top cover opening if additional active cooling is required and ensure proper airflow paths through ventilation slots.

Usage recommendations

Keep weight distributed evenly across the rails and place heavier equipment toward the lower U positions to maintain stability. Use cable organisers and the provided vertical ducts to avoid obstructing airflow. For installations exposed to dust or higher humidity, consider additional environmental controls beyond the IP20 rating. Verify available depth and rail position before ordering equipment to ensure compatibility.
