Patch panel ROLINE 1U, 4 x 6 mm openings, model 19RANGIERPANEL ROLINE 1 HE 4X6MM SW

ROLINE 19RANGIERPANEL ROLINE 1 HE 4X6MM SW is a 1U rack-mounted patch panel designed for cable routing and tidy termination in server racks and equipment cabinets. The panel features four openings with 6 mm diameter each, providing guided passage and anchoring points for network and patch cables. Supplied in a single height (1U), it is compatible with standard 19-inch rack systems and intended for use in data centers, server rooms and telecommunications cabinets where organized cabling is required.

Advantages

The patch panel offers a compact, space-saving solution for cable management in a 1U form factor. Four 6 mm openings allow controlled cable entry and reduce strain on terminations. Constructed for rack installation, the panel helps maintain clear cable paths and improves accessibility for maintenance and reconfiguration. The neutral finish and simple design make it suitable for integration into existing rack installations without requiring additional accessories.

Suitable for

• Organizing horizontal and vertical cable runs in 19-inch racks
• Use in server rooms and data centers for structured cabling
• Telecommunications and network cabinets where space-efficient routing is needed
• Environments requiring accessible termination and straightforward maintenance

Key specifications

• Form factor: 1U (single rack unit) compatible with 19-inch racks
• Openings: 4 openings with 6 mm diameter each for cable passage
• Mounting: Rack-mountable panel for installation in equipment cabinets
• Function: Cable routing and termination support for structured cabling
• Application areas: Data centers, server rooms, telecommunications cabinets

How to use

Install the panel into a standard 19-inch rack occupying a single U of space, securing it with appropriate rack screws. Route cables through the four 6 mm openings to guide and group cable bundles, ensuring that cable bends respect manufacturer minimum bend radius. Use the panel as an intermediate routing or termination point, keeping cables organized for labeling and access during maintenance or reconfiguration.

Usage recommendations

Position the panel near patching points or entry locations to minimize cable length and crossing. Avoid overfilling the 6 mm openings; route only the number of cables that preserve proper bend radius and do not create strain on connectors. Periodically check and adjust cable routing to maintain accessibility and airflow in the rack.
