SANHA Copper PRESS 90° Elbow 1/4" — SANHA model 132002A14

SANHA Copper PRESS 90° Elbow 1/4" is a press-fit copper fitting designed to create a permanent, leak-resistant 90-degree joint for 1/4" pipe connections. The elbow provides a compact right-angle change of direction and is intended for use in plumbing, heating and refrigeration installations. It is compatible with standard press tools and matched seals for reliable mechanical connections without soldering.

Advantages

The press connection on this copper elbow delivers a fast and consistent joint that reduces installation time compared with soldering. Made from copper, the fitting offers corrosion resistance and thermal conductivity suitable for potable water, heating circuits and refrigeration lines. The compact 90° geometry allows neat routing in confined spaces and supports durable, vibration-resistant connections when installed with appropriate press tools and seals.

Suitable for

• Domestic and commercial potable water supply lines
• Heating systems including radiators and underfloor heating manifolds
• Refrigeration and air conditioning liquid lines
• Tight or compact installations where a right-angle change of direction is needed

Key specifications

• Material: copper
• Connection type: press-fit joint compatible with standard press tools and seals
• Angle: 90° elbow
• Nominal pipe size: 1/4"
• Application: potable water, heating and refrigeration lines
• Installation: mechanical press connection — no soldering required

How to use

Prepare the copper pipe by cutting square and deburring the end. Verify the selected press-fit seal is compatible with the pipe material and press tool used. Insert the pipe fully into the elbow until it seats against the stop, then position the press tool over the fitting collar and activate the press cycle according to the tool manufacturer's instructions. Confirm the joint is compressed evenly and that the seal is intact. After pressing, perform a pressure test appropriate to the system to verify leak-tightness.

Usage recommendations

Use only certified press tools and the manufacturer-recommended seals for reliable joints. Avoid using the fitting in systems with media or temperatures outside copper's recommended service limits. In potable water applications follow local codes and flush the system after installation. For refrigeration systems, ensure compatibility with refrigerants and follow industry safety procedures when charging and testing.
